Description
Sargent 706-4-ETL-10BE LHR LESS CYLINDER Storeroom Exit Trim Kit, Key Unlocks Relocks, LHR, Dark Bronze, Less Cylinder
Sargent 706-4-ETL-10BE LHR LESS CYLINDER KIT offers a robust solution for storeroom exit needs, featuring a key that unlocks the exit trim and relocks once removed. Designed with a left-hand reverse handing, this model is crafted from dark oxidized bronze (613E/US10BE) for a sophisticated and durable finish. It is compatible with a variety of exit devices, including the AD8406, MD8406, AD8606, MD8606, and WD8606, making it a versatile choice for various applications. This exit trim features a sleek escutcheon with an L lever, allowing for convenient one-hand operation. It is non-handed and securely through-bolted to the chassis, ensuring enhanced durability and security. The trim supports multiple functions, including night latch and key retract options, catering to diverse locking requirements.The Sargent 706-4-ETL also accommodates various finishes and lever designs, allowing customization to fit different aesthetics. Its ANSI/BHMA-rated finishes ensure that it meets high standards of quality and performance. Elevate security without compromising style with the Sargent 706-4-ETL-10BE, a reliable choice for both professionals and discerning homeowners.
KIT – Storeroom Exit Trim (Key Unlocks Exit Trim, Relocks When Key is Removed), Less 41 Mortise Cylinder, Escutcheon with L Lever, LHR Left Hand Reverse, 613E/US10BE Dark Oxidized Bronze (Works with (12) AD8406, MD8406, AD8606, MD8606 and WD8606)
Notice: The info below is not item specific.
The 700 series ET control is sold separately from the exit device and can be used with 8888 & 8810 exit device. The trim is non handed and is through bolted to the chassis for greater security and durability. Available in 7 functions and Sargent studio, coastal and standard lever designs to accommodate most requirements.
Features:
- ANSI/BHMA Finishes
- Easy operating lever handle allows convenient one hand operation
- ET trim is not available in 32 or 32D
- Stainless steel levers are available
Functions:
- 04: Night latch key retracts latch #34 cylinder supplied. ANSI 03
- 10: No O/S operation or cylinder (pull only). ANSI 02
- 13: Key outside unlocks/locks trim #41 cylinder supplied. ANSI 08
- 15: Passage only (no cylinder). ANSI 14
- 63: Key outside unlocks/locks thumbpiece #34 cylinder supplied. ANSI 05
- 66: Key outside retracts latch; key inside unlocks/locks O/S trim O/S #34 & I/S #44. ANSI 07
- 73: Electrified ET trim – fail safe power off, unlocks lever (no cylinder)
- 74: Electrified ET trim – fail secure power off, locks lever (no cylinder)
- 75: Electrified ET trim – fail safe power off, unlocks lever, key retracts latch #34 cylinder supplied
- 76: Electrified ET trim – fail secure power off, locks lever, key retracts latch #34 cylinder supplied
Finishes:
- 0-3/605 – Bright brass, clear coated
- 0-4/606 – Satin brass, clear coated
- 0-9/611 – Bright bronze, clear coated
- 1-0/612 – Satin bronze, clear coated
- 10B/613 – Dark oxidized satin bronze, oil rubbed
- 10BE/613E – Dark oxidized satin bronze, equivalent
- 10BL/613L – Dark oxidized satin bronze clear coated
- 20D/624 – Dark statuary bronze lacquered
- 2-6/625 – Bright chrome plated
- 26D/626 – Satin chrome plated
- 3-2/629 – Bright stainless steel
- 32D/630 – Satin stainless steel
- BSP – Black suede powder coat
- WSP – White suede powder coat
Attributes
Alternate Codes: 706-4-ETL-10BE LHR LESS CYLINDER, 7064ETL10BELHRLESSCYLINDER
Category: Panic Devices & Exit Alarms, Panic Device Trims
Cylinder Type: Less Cylinder
Door Application: Panic Devices & Exit Alarms
Finish Code: 613E
Finish Color: Dark Oxidized Satin Bronze
Handing: Left Handed Reverse
