Description
Sargent 706-4-ETL-BSP LHR LESS CYLINDER Storeroom Exit Trim Kit, Key Unlocks, Relocks, LHR, BSP Black Suede Finish
Sargent 706-4-ETL-BSP LHR LESS CYLINDER KIT offers a reliable and secure storeroom exit trim solution, designed for ease of use and enhanced security. This model features a key that unlocks the exit trim and automatically relocks when removed, ensuring controlled access. The kit comes without a mortise cylinder, allowing for customization based on specific security needs. The escutcheon is complemented by a stylish L lever, ensuring both functionality and aesthetic appeal. Crafted for durability, the trim is through-bolted to the chassis, providing increased security. The non-handed design means it can be adapted for various door applications, making it versatile for any project. Available in a sleek black suede powder coat finish (BSP), it is an ideal choice for modern environments. This exit trim works seamlessly with specific Sargent exit devices, including the AD8406, MD8406, AD8606, MD8606, and WD8606, expanding its usability. With ANSI/BHMA finishes and easy one-hand operation, this product is engineered to meet the demands of both building professionals and knowledgeable homeowners. Choose the Sargent 706-4-ETL-BSP for a reliable, stylish, and functional exit trim solution that enhances security without compromising on design.
KIT – Storeroom Exit Trim (Key Unlocks Exit Trim, Relocks When Key is Removed), Less 41 Mortise Cylinder, Escutcheon with L Lever, LHR Left Hand Reverse, BSP Black Suede Powder Coat (Works with (12) AD8406, MD8406, AD8606, MD8606 and WD8606)
Notice: The info below is not item specific.
The 700 series ET control is sold separately from the exit device and can be used with 8888 & 8810 exit device. The trim is non handed and is through bolted to the chassis for greater security and durability. Available in 7 functions and Sargent studio, coastal and standard lever designs to accommodate most requirements.
Features:
- ANSI/BHMA Finishes
- Easy operating lever handle allows convenient one hand operation
- ET trim is not available in 32 or 32D
- Stainless steel levers are available
Functions:
- 04: Night latch key retracts latch #34 cylinder supplied. ANSI 03
- 10: No O/S operation or cylinder (pull only). ANSI 02
- 13: Key outside unlocks/locks trim #41 cylinder supplied. ANSI 08
- 15: Passage only (no cylinder). ANSI 14
- 63: Key outside unlocks/locks thumbpiece #34 cylinder supplied. ANSI 05
- 66: Key outside retracts latch; key inside unlocks/locks O/S trim O/S #34 & I/S #44. ANSI 07
- 73: Electrified ET trim – fail safe power off, unlocks lever (no cylinder)
- 74: Electrified ET trim – fail secure power off, locks lever (no cylinder)
- 75: Electrified ET trim – fail safe power off, unlocks lever, key retracts latch #34 cylinder supplied
- 76: Electrified ET trim – fail secure power off, locks lever, key retracts latch #34 cylinder supplied
Finishes:
- 0-3/605 – Bright brass, clear coated
- 0-4/606 – Satin brass, clear coated
- 0-9/611 – Bright bronze, clear coated
- 1-0/612 – Satin bronze, clear coated
- 10B/613 – Dark oxidized satin bronze, oil rubbed
- 10BE/613E – Dark oxidized satin bronze, equivalent
- 10BL/613L – Dark oxidized satin bronze clear coated
- 20D/624 – Dark statuary bronze lacquered
- 2-6/625 – Bright chrome plated
- 26D/626 – Satin chrome plated
- 3-2/629 – Bright stainless steel
- 32D/630 – Satin stainless steel
- BSP – Black suede powder coat
- WSP – White suede powder coat
Attributes
Alternate Codes: 706-4-ETL-BSP LHR LESS CYLINDER, 7064ETLBSPLHRLESSCYLINDER
Category: Panic Devices & Exit Alarms, Panic Device Trims
Cylinder Type: Less Cylinder
Door Application: Panic Devices & Exit Alarms
Finish Code: BSP
Finish Color: Black Suede Powder Coat
Handing: Left Handed Reverse
