Description
Marks Hardware 175L/26D Privacy Lock Guide
Marks Hardware 175L/26D Privacy Lock delivers exceptional security and reliability for commercial applications. This Grade 2 cylindrical lock features a privacy function, making it ideal for restrooms or private offices. The key in lever cylinder is equipped with six pins, ensuring enhanced protection against unauthorized access. With a robust 3-1/4″ rose diameter and a satin chrome finish, this lock not only looks professional but also stands the test of time. This lockset is part of the Marks USA Survivor Series, known for its durability and backed by a lifetime mechanical warranty. It meets ADA compliance and is UL Listed for a fire rating of up to three hours, making it a safe choice for high-traffic areas. The 2-3/4″ backset and non-handed design facilitate easy installation on doors ranging from 1-5/8″ to 1-7/8″ thick. With a bolt projection of 1/2″ and ANSI function F76, the Marks 175L/26D is designed for seamless operation. It includes two cut keys, and the Schlage C standard keyway adds an extra layer of convenience. Choose the Marks Hardware 175L/26D Privacy Lock for a reliable, secure, and stylish solution for your door hardware needs.
Privacy Lock
Grade 2 Cylindrical Lock, Privacy Function, Key in Lever Cylinder, 6-Pin, American Lever, 3-1/4″ Rose Diameter, ASA Strike, 2-3/4″ Backset, Satin Chrome Finish, Non-Handed
Marks USA Survivor Series locksets are the most durable cylindrical lever locksets. The Survivor Series locksets are backed by Marks lifetime mechanical warranty. All functions are available in six standard finishes, are UL Listed for 3-hour fire rating, and satisfy ADA requirements.
Attributes
Accessible: Yes
Ada Compliance: Yes
Ansi: A156.2
Ansi Function: F76
Baa Qualified: Yes
Bolt Projection: 1/2″
Burglar Rated: No
Commercial Residential: Commercial
Country of origin: USA
Cylinder Type: Key in Lever Cylinder
Door Thickness: 1-5/8″ to 1-7/8″
Finish: 626/US26D
Finish Family: Matte Silver
Fire Rated: 3 Hours {A}
Fire Rating: 3 Hours {A}
Function: L-Privacy
Grade: Grade 2
Handing: Non-Handed
Installation: Commercial
Keying: Keyed Different
Keys: Cut
Leverknob Design: 175 – American Lever
Limited Warranty: Lifetime
Lock Face Size: 1-1/8″ x 2-1/4″
Of Keys: 2
Origin: USA
Pack Qty: 1
Pins: 6
Restrictions: None
Roseescutcheon Design: 3-1/4″ Rose Diameter
Screws: Combination
Series: Marks Survivor Series Cylindrical Locksets
Std Keyway: Schlage C
Std Latch Backset Dim: 2-3/4″
Std Latch Number: 1134
Std Strike Number: 1145
Std Strike Type: ASA Strike
Subtype: Cylindrical Lock
Type: Locks, Cylinders, Cores, Keyblanks
Ul Listing: UL 10C
Unit of Measure: Each
Resources
- Marks Survivor Series Cylindrical Locksets Cut Sheet
