Description
Marks Hardware 495L/26D Privacy Lock Instructions
Marks Hardware 495L/26D Privacy Lock delivers exceptional security and durability with its Grade 1 cylindrical design, making it an ideal choice for commercial applications. This non-keyed privacy lock features a stylish Titan lever and a 3-7/16″ rose diameter, ensuring a sleek and modern look that complements any door. The lock is designed with a 2-3/4″ backset and includes an ASA curved lip strike for seamless installation. Constructed as part of the Survivor Series, this lockset is backed by a lifetime mechanical warranty, assuring you of its long-lasting performance. With a fire rating of 3 hours, it meets UL standards, providing peace of mind in emergency situations. The 495L/26D is also compliant with ADA requirements, making it accessible for all users. Designed for doors with a thickness ranging from 1-5/8″ to 1-7/8″, this non-handed lock is versatile and easy to install. The satin chrome finish (626/US26D) not only enhances aesthetic appeal but also ensures resistance to wear and tear. With a bolt projection of 9/16″ and a standard latch backset dimension of 2-3/4″, the Marks 495L/26D Privacy Lock is a reliable choice for any professional seeking quality and security in door hardware.
Privacy Lock
Grade 1 Cylindrical Lock, Privacy Function, Non-keyed, Titan Lever, 3-7/16″ Rose Diameter, ASA Curved Lip Strike, 2-3/4″ Backset, Satin Chrome Finish, Non-Handed
Marks USA Survivor Series locksets are the most durable cylindrical lever locksets. The Survivor Series locksets are backed by Marks lifetime mechanical warranty. All functions are available in six standard finishes, are UL Listed for 3-hour fire rating, and satisfy ADA requirements.
Attributes
Accessible: No
Ada Compliance: No
Ansi: A156.2
Ansi Function: F76
Baa Qualified: Yes
Bolt Projection: 9/16″
Bore Hole Diameter: 2-1/8″
Burglar Rated: No
Commercial Residential: Commercial
Country of origin: USA
Cylinder Type: Non-keyed
Door Thickness: 1-5/8″ to 1-7/8″
Finish: 626/US26D
Finish Family: Matte Silver
Fire Rated: 3 Hours {A}
Fire Rating: 3 Hours {A}
Function: L-Privacy
Grade: Grade 1
Handing: Non-Handed
Installation: Commercial
Latch Bore Diameter: 1″
Leverknob Design: 495 – Titan Lever
Leverknob Design Family: Straight Lever
Limited Warranty: Lifetime
Lock Face Size: 1-1/8″ x 2-1/4″
Origin: USA
Pack Qty: 1
Projection: 2-7/8″
Restrictions: None
Roseescutcheon Design: 3-7/16″ Rose Diameter
Screws: Combination
Series: Marks Survivor Series Cylindrical Locksets
Std Latch Backset Dim: 2-3/4″
Std Latch Number: 1834L
Std Latch Type: Spring Latch (Unguarded)
Std Strike Height: 4-7/8″
Std Strike Number: 1135
Std Strike Type: ASA Curved Lip Strike
Std Strike Width: 1-1/4″
Subtype: Cylindrical Lock
Type: Locks, Cylinders, Cores, Keyblanks
Ul Listing: UL 10C
Unit of Measure: Each
Resources
- Marks Survivor Series Cylindrical Locksets Cut Sheet
