Description
Von Duprin 8875L US4 RHR L/TRIM Mortise Crossbar Exit 606
Von Duprin 8875L US4 RHR L/TRIM Mortise Crossbar Exit 606 is a Grade 1 mortise exit device designed for both single and double doors, ensuring robust security and reliability. With its 48-inch wide stile crossbar and classroom function, this exit device is ideal for commercial environments requiring secure egress solutions. The unit features hex key dogging for ease of operation and comes in a sophisticated satin brass finish that complements various architectural styles. Designed for stock hollow metal doors with 86 cutouts, the 8875L is compatible with door stiles as narrow as 4 3/4 inches, making it versatile for different applications. This device is field reversible, providing flexibility during installation, while the 3/4-inch anti-friction latch bolt enhances security and functionality. The adjustable faceplate ensures a perfect fit, and field selection of functions allows for customization based on specific needs. Measuring 36 13/16 inches from the floor to the crossbar centerline, this device is engineered with user accessibility in mind. It includes a comprehensive screw pack for installation on 1 3/4-inch and 2 1/4-inch thick doors, making it an excellent choice for various commercial settings. Trust Von Duprin for reliable performance and peace of mind.
Mortise Crossbar Exit 606
Grade 1 Mortise Exit Bar, Wide Stile Crossbar, 48″ Device, Classroom Function, Less Trim, Hex Key Dogging, Satin Brass Finish, Field Reversible, Right Hand Reverse
8875 mortise lock devices or all types of single or double doors, UL listed for accident hazard installations. Fits stock hollow metal doors with 86 cutouts and door stiles as narrow as 4 3/4″ (121 mm). This device is field reversible but comes handed from factory. The 7500 mortise lock is equipped with a 3/4″ (19 mm) anti-friction latch bolt which is field reversible without removing the lock from the door. It has a non-handed auxiliary bolt for deadlocking and a faceplate with an adjustable bevel. Field selection of functions are furnished standard. TP and K function may be field selected by turning down a set screw in mortise lock body. Electric locking or unlocking options are available.
Fits stock hollow metal doors with 86 cutouts and door stiles as narrow as 4 3/4″ (121 mm).
8875 Series is for all types of single and double doors with mullion, UL listed for accident hazard installations.
- Device functions Device ships EO, DT, NL, TP, K, L
- Handing Handed
- Crossbar length 42″ (1067 mm) field sizable Device centerline 39 13/16″
- Crossbar centerline to finished floor 36 13/16″ (935 mm) at center
- Latch bolt height to finished floor 40 3/32″ (1018 mm) at center
- Lock stile case 8 1/4″ x 2 x 15/16″ (210 mm x 51 mm x 24 mm)
- Lock case 4 5/8″ x 5 3/4″ x 1 1/16″ (117 mm x 146 mm x 27 mm)
- Faceplate 1 1/4″ x 8″ x 7 /32″ (32 mm x 203 mm x 6 mm)
- Cylinder backset 2 3/4″ (70 mm)
- Hinge stile case 6″ x 1 3/4″ x 15/16″ (152 mm x 44 mm x 24 mm)
- Crossbar tubing 1″ (25 mm) outside diameter
- Projection Neutral – 4 7/8″ (124 mm) Depressed – 4″ (102 mm)
- Latchbolt Deadlocking – 3 /4″ (19mm) throw
- Fasteners and sex bolts (SBN) Includes screw pack for 1 3/4″ (44 mm) and 2 1/4″ (57 mm) thick metal or wood doors. Sex nuts and bolts included
Attributes
Manufacturer surcharge: 4.5%
Base Material: Brass
Commercial Residential: Commercial
Cylinder Type: 1-1/4″ Mortise
Device Length: 48″
Device Type: Mortise
Dogging Options: Hex Key Dogging
Door Height: 84″
Door Material: All Types
Door Thickness: 1-3/4″
Door Width: 3′ – 4′
Finish: 606/US4
Finish Family: Matte Brass
Fire Rated: No
Grade: Grade 1
Handing: Right Hand Reverse
Includes Cylinders: No
Includes Trim: No
Installation: Commercial
Limited Warranty: 3 Years
Mechanical Function: Classroom
Minimum Stile Size: 4-3/4″
Pack Qty: 1
Physical Appearance: Wide Stile Crossbar
Reversible: Yes
Series: 8875 Series Mortise Crossbar Devices
Strike Standard: 575
Subtype: Mortise Exit Devices
Trim Design: Lever with Escutcheon
Trim Type: Lever
Type: Exit Devices
Unit of Measure: Each
Resources
- 88 Series Rim Crossbar Devices;8875 Series Mortise Crossbar Devices Cut Sheet
- 8875/8875-F Wood Door Template
- E88K Series Wood Door Template
- E88TP Series Wood Door Template
- Von Duprin Finishes Chart
