Description
Von Duprin 8875L-F 26D RHR L/TRIM Mortise Crossbar Exit 626
Von Duprin 8875L-F 26D RHR L/TRIM Mortise Crossbar Exit is a Grade 1 Mortise Exit Bar designed for commercial applications, ensuring both safety and reliability. This 48″ fire-rated device features a robust wide stile crossbar and a classroom function, making it ideal for high-traffic environments. The satin chrome finish not only enhances its aesthetic appeal but also ensures durability. Engineered to fit single doors as wide as 48″ and double doors with mullions, this exit device accommodates door stiles as narrow as 4 3/4″. It boasts a field-reversible design, allowing for easy installation without removing the lock from the door. The 8875L-F includes a non-handed auxiliary bolt for added security and allows for field selection of various functions, including electric locking options. Designed with practicality in mind, the device’s centerline is set at 36 13/16″, suitable for standard installations. With an adjustable faceplate and a latch bolt that features a 3/4″ throw, it meets UL listings for accident hazard installations, providing peace of mind. For optimal performance, the device is compatible with stock hollow metal doors and includes a comprehensive screw pack for versatile installation. Enhance your building’s safety with the Von Duprin 8875L-F.
Mortise Crossbar Exit 626
Grade 1 Mortise Exit Bar, Wide Stile Crossbar, 48″ Fire-Rated Device, Classroom Function, Less Trim, Less Dogging, Satin Chrome Finish, Field Reversible, Right Hand Reverse
8875-F mortise lock fire exit devices for all types of 4 Ft. X 8 Ft. (1219 mm X 2438 mm) single and 8 Ft. X 8 Ft. (2438 mm x 2438 mm), UL listed, 3 hours. Fits door stiles as narrow as 4 3/4″ (121 mm). The 7500 mortise lock is field reversible without removing the lock from the door. It has a non-handed auxiliary bolt for deadlocking and a faceplate with an adjustable bevel. Field selection of functions are furnished standard. TP and K function may be field selected by turning down a set screw in mortise lock body. Electric locking or unlocking options are available.
Fits stock hollow metal doors with 86 cutouts and door stiles as narrow as 4 3/4″ (121 mm).
8875 Series is for all types of single and double doors with mullion, UL listed for accident hazard installations.
- Device functions Device ships EO, DT, NL, TP, K, L
- Handing Handed
- Crossbar length 42″ (1067 mm) field sizable Device centerline 39 13/16″
- Crossbar centerline to finished floor 36 13/16″ (935 mm) at center
- Latch bolt height to finished floor 40 3/32″ (1018 mm) at center
- Lock stile case 8 1/4″ x 2 x 15/16″ (210 mm x 51 mm x 24 mm)
- Lock case 4 5/8″ x 5 3/4″ x 1 1/16″ (117 mm x 146 mm x 27 mm)
- Faceplate 1 1/4″ x 8″ x 7 /32″ (32 mm x 203 mm x 6 mm)
- Cylinder backset 2 3/4″ (70 mm)
- Hinge stile case 6″ x 1 3/4″ x 15/16″ (152 mm x 44 mm x 24 mm)
- Crossbar tubing 1″ (25 mm) outside diameter
- Projection Neutral – 4 7/8″ (124 mm) Depressed – 4″ (102 mm)
- Latchbolt Deadlocking – 3 /4″ (19mm) throw
- Fasteners and sex bolts (SBN) Includes screw pack for 1 3/4″ (44 mm) and 2 1/4″ (57 mm) thick metal or wood doors. Sex nuts and bolts included
Attributes
Manufacturer surcharge: 4.5%
Base Material: Brass or Bronze
Commercial Residential: Commercial
Cylinder Type: 1-1/4″ Mortise
Device Length: 48″
Device Type: Mortise
Dogging Options: Less Dogging
Door Height: 84″
Door Material: All Types
Door Thickness: 1-3/4″
Door Width: 36″ to 48″
Finish: 626/US26D
Finish Family: Matte Silver
Fire Rated: Yes
Fire Rating: Yes {Variable}
Grade: Grade 1
Handing: Right-Hand Reverse
Includes Cylinders: No
Includes Trim: No
Installation: Commercial
Limited Warranty: 3 Years
Mechanical Function: Classroom
Mechanical Options: Fire Rated
Minimum Stile Size: 4-3/4″
Pack Qty: 1
Physical Appearance: Wide Stile Crossbar
Reversible: Yes
Series: 8875 Series Mortise Crossbar Devices
Strike Standard: 575
Subtype: Mortise Exit Devices
Trim Design: Lever with Escutcheon
Trim Type: Lever
Type: Exit Devices
Unit of Measure: Each
Resources
- 88 Series Rim Crossbar Devices;8875 Series Mortise Crossbar Devices Cut Sheet
- 8875/8875-F Wood Door Template
- E88K Series Wood Door Template
- E88TP Series Wood Door Template
- Von Duprin Finishes Chart
