Arrow Lock BM22 VG 10 IC7 Office Mortise Lock
Arrow Lock BM22 VG 10 IC7 Mortise Lock – Office offers a robust solution for high-security applications in commercial settings. Designed for heavy-duty use, this mortise lock features a V lever and G escutcheon, perfect for office environments where reliability and performance are paramount.Constructed from heavy gauge steel with a zinc dichromate finish, the lock case ensures exceptional corrosion resistance, making it ideal for schools, hospitals, and other institutional buildings. The BM Series includes a field-reversible handing feature, allowing easy adaptation without disassembling the lockcase, thus enhancing its versatility. With a standard door thickness of 1-3/4″ and a backset of 2-3/4″, this lock accommodates a wide range of door configurations. The stainless steel latchbolt boasts a 5/8″ x 1″ throw, while the auxiliary latchbolt and one-piece deadbolt provide additional security measures. The lock’s faceplate, available in wrought brass or bronze, is attached with machine screws for added durability. Arrow’s BM22 Mortise Lock also supports various keying options, including master keying and interchangeable cores, ensuring comprehensive control over access. With a five-year limited warranty, this lock combines strength, security, and low maintenance for lasting peace of mind in any office setting.
Mortise Lock – Office
Office Mortise Lock, V Lever, G Escutcheon, SFIC Prep Less Core, Satin Bronze
Arrow mortise locks are offered in a complete range of functions designed for commercial, institutional and industrial applications. They are engineered for strength and performance, and precisely manufactured to exacting standards. Arrow mortise locks are intended for heavy duty use in schools, hospitals and commercial buildings where security, durability and low maintenance are required. The lock case is made from heavy gauge steel, with zinc dichromate finish for corrosion resistance and it can be re-handed without disassembling the lock case. A wide selection of trim designs and functions are offered which meet or exceed the performance requirements of ANSI Grade 1.
The BM Series are engineered for strength and performance, and precisely manufactured to exact standards.
Arrow BM Series Lever Mortise Locks are intended for heavy duty use in schools, hospitals and commercial buildings where security, durability and low maintenance are required.
- Handing:Handed; field reversible. The lockset can be re-handed without disassembling the lock case.
- Door Thickness:1-3/4″ (4mm) standard. Optional door thickness available; consult factory.
- Backset:2-3/4″ (70mm).
- Lockcase:Heavy gauge steel, with zinc dichromate finish for corrosion resistance. 5-7/8″ (149mm) x 4″ (102mm) x 15/16″ (24mm).
- Armored Front:Heavy gauge steel, 8″ (203 mm) x 1-1/4″ (32mm) x 3/32″ (2mm). Accommodates flat doors and doors beveled 1/8″ (3mm) in 2″ (51mm).
- Faceplate:Wrought brass or bronze, attached by machine screws to lockcase front.
- Latchbolt:Stainless steel, 2 piece mechanical with anti-friction insert. 5/8″ (16mm) x 1″ (25mm) x 3/4″ (19mm) throw.
- Auxiliary Latchbolt:9/16″ (14mm) effective throw and 3/8″ (10mm) effective auxiliary latch deadlocking.
- Deadbolt:One-piece stainless steel, 19/32″ (15mm) x 1 1/4″ (32mm) x 1″ (25mm) throw.
- Hub:Lever: nickel steel, 5/16″ (8mm).
- Spacing:Center to center, hub to cylinder: 3-5/8″ (92mm).
- Center to center, hub to turnpiece: 2-7/16″ (62 mm).
- Strike:Wrought brass or bronze, ANSI straight lip standard, 4-7/8″ (124mm) x 1-1/4″ (32mm) 1-1/8″ (29mm) lip to center. Optional strikes, lip lengths and ANSI wrought strike box available.
- Keys:Two nickel silver standard.
- Keying Features Available:
- Master keying
- Construction master keying
- Visual key control
- Concealed key control
- High security cylinder
- Interchangeable core (IC) – Pointe, Pointe Flex
- Warranty:Five-year limited.
Attributes
Ansi Function: F04 – Entry/Office
Application: Complete Lock
Base Material: Bronze
Bolt Projection: 3/4″
Cylinder Type: SFIC Prep Less Core
Door Thickness: 1-3/4″
Finish: 612/US10
Fire Rated: 3 Hours {A}
Fire Rating: 3 Hours {A}
Function: 22-Office
Grade: Grade 1
Handing: Field Reversible
Leverknob Design: V – Lever
Limited Warranty: 5 Years
Lock Face Size: 8″ x 1-1/4″
Pack Height: 4.5″
Pack Length: 9.25″
Pack Qty: 1
Pack Volume: 239.34 in³
Pack Width: 5.75″
Product Height: 8″
Product Length: 2.88″
Product Width: 2.25″
Roseescutcheon Design: G – Escutcheon
Screws: Combination
Series: BM Series Mortise Locks
Ship Weight: 6 lbs.
Std Strike Height: 4-7/8″
Std Strike Number: 463
Std Strike Type: ASA
Std Strike Width: 1-1/4″
Subtype: Mortise Lock
Type: Locks, Cylinders, Cores, Keyblanks
Unit of Measure: Each
