Von Duprin 5575L-06 26D RHR Narrow MTS Crossbar Exit 626
Von Duprin 5575L-06 26D RHR Narrow MTS Crossbar Exit 626 is a Grade 1 Mortise Exit Bar designed for both functionality and style. This 48-inch narrow stile crossbar is ideal for classroom applications, featuring a sleek satin chrome finish that complements modern and historical architecture alike. The device operates with a 06 lever and escutcheon trim, providing a sophisticated touch without a cylinder, making it perfect for areas requiring controlled access. Designed to fit single and double doors with mullions, the 55 Series devices accommodate door stiles as narrow as 1 3/4 inches. The concealed vertical rod exit device ensures safety while maintaining an unobtrusive appearance. With hex key dogging functionality, securing the exit is straightforward and efficient. Key specifications include a crossbar length of 42 inches and a height to the finished floor of 36 13/16 inches. The latch bolt features a 3/4-inch throw for reliable security. Installation hardware is included, making setup on both metal and wood doors straightforward. As a UL-listed device for accident hazard installations, the Von Duprin 5575L-06 delivers peace of mind in safety and compliance. With a limited three-year warranty, this exit device is both a durable and stylish choice for commercial applications.
Narrow MTS Crossbar Exit 626
Grade 1 Mortise Exit Bar, Narrow Stile Crossbar, 48″ Device, Classroom Function, 06 Lever with Escutcheon Trim, Less Cylinder, Hex Key Dogging, Satin Chrome Finish, Right Hand Reverse
The 55 Series from Von Duprin are exit device crossbars with a classic design. The 55 Series is a narrow stile device and commonly used in retro-inspired architecture and historical buildings.
Concealed Vertical Rod Exit Device, Dummy Trim.
55 Seriesdevices for all types of single and double doors with mullion, UL listed for accident hazard installations. Fits doors stiles as narrow as 1 3/4″ (44 mm).
- Device functions Device ships EO/DT/NL/L
- Crossbar length 42″ (1067 mm)
- Crossbar height to finished floor 36 13/16″ (935 mm) at center
- Lock stile case 7 1 /4″ x 1 3 /16″ x 2 1 /4″ (184 mm x 30 mm x 57 mm)
- Hinge stile case 7 1 /4″ x 1 3 /16″ x 2 1 /4″ (184 mm x 30 mm x 57 mm)
- Crossbar tubing 1″ (25 mm)
- Projection Crossbar neutral – 3 3/4″ (95 mm) Crossbar depressed – 2 3/8″ (60 mm)
- Latch bolt 3/4″ (19 mm), throw
- Fasteners and Sex bolts (SBN) Includes screw pack for 1 3/4″ (44 mm) and 2 1/4″ (57 mm) thick metal or wood doors. Sex nuts and bolts included.
Attributes
Manufacturer surcharge: 4.5%
Base Material: Brass or Bronze
Commercial Residential: Commercial
Cylinder Type: Mortise
Device Length: 48″
Device Type: Mortise
Dogging Options: Hex Key Dogging
Door Material: All Types
Door Thickness: 1-3/4″
Door Width: 3′ – 4′
Finish: 626/US26D
Finish Family: Matte Silver
Fire Rated: No
Grade: Grade 1
Handing: Right Hand Reverse
Includes Cylinders: No
Includes Trim: Yes
Installation: Commercial
Limited Warranty: 3 Years
Mechanical Function: Classroom
Minimum Stile Size: 4-3/4″
Pack Qty: 1
Physical Appearance: Narrow Stile Crossbar
Product Length: 48″
Reversible: No
Series: 55 Series Narrow Style Crossbar Devices
Strike Standard: 575
Subtype: Mortise Exit Devices
Trim Design: Lever with Escutcheon
Trim Part No: 375L-06 26D RHR
Trim Type: Lever
Type: Exit Devices
Unit of Measure: Each
Resources
- 55 Series Exit Device Service Manual
- 55 Series Narrow Style Crossbar Devices Cut Sheet
- 5547WDC & 5547WDC-F Series Wood Door Template
- 5575 & 5575-F Mortise Lock Wood Door Template
- Von Duprin Finishes Chart
