CRL 0PF10RPS Polished Stainless Right Offset Bottom Door Patch Fitting
CRL 0PF10RPS Polished Stainless Right Offset Bottom Door Patch Fitting offers an exceptional solution for creating sleek, functional glass door systems. Designed to accommodate a full 180º door swing, this fitting is suitable for 3/8″ or 1/2″ (10 or 12 mm) glass, ensuring versatility in various applications. Available in both left and right-handed configurations, it caters to diverse installation needs while adding a touch of elegance with its polished stainless steel finish. Constructed with a high-density cast body, this bottom door patch fitting includes cover plates in your chosen finish, a gasket for proper sealing, and comprehensive templates and instructions for easy glass fabrication. It is compatible with CRL8300 and CRL8400 Series Floor Closers, as well as several adjustable bottom free swinging pivots, making it an adaptable choice for professional projects. For installation, a 3/4″ (19 mm) diameter hole and corner notch are required in the glass. While stainless steel provides corrosion resistance, regular maintenance is recommended to preserve its factory finish. Enhance your next architectural project with the durability and stylish appeal of the CRL 0PF10RPS fitting, a standout component for modern glass installations.
Polished Stainless Right Offset Bottom Door Patch Fitting
- Allows for 180º Door Swing
- For 3/8″ or 1/2″ (10 or 12 mm) Glass
- Left and Right Handed
The
CRL Bottom of Door Offset Patch Fitting is designed to work with any of our other offset fittings. Allowing for a full 180º door swing, these fittings are available for right or left hand configurations, in your choice of brushed or polished stainless steel. Glass fabrication templates are included in the box.
INCLUDES:
– High Density Cast Body
– Cover Plates (Finish of Your Choice)
– Gasket for 3/8″ or 1/2″ (10 or 12.7 mm) Glass
– Template and Instructions
SPECIFICATIONS:
For Use With:
– CRL8300 Series Floor Closers
– CRL8400 Series Floor Closers
– INT402 Bottom Free Swinging Pivot
– INT403 Adjustable Bottom Free Swinging Pivot
– INT406 Adjustable Bottom Free Swinging Pivot
Glass Fabrication Required:
One 3/4″ (19 mm) Diameter
Hole and Corner Notch
Comes With: Template and Instructions
Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer’s video card and on how your monitor’s color is adjusted.
Stainless Steel Advisory:
Although Stainless Steel is resistant to corrosion, it is not rust or stain proof. CRL recommends periodic maintenance to help maintain its factory finish. For more information, view the Stainless Steel Disclaimer found in the Technical References section below.
Attributes
Compliance and Restrictions: Warning Reproductive Harm – www.p65warnings.ca.gov
Finish/ Color:: Polished Stainless Steel
Glazing Thickness: 3/8 in., 1/2 in. (10 mm, 12 mm)
Handing: Right Hand
Series: Offset
Shipping Limitations: None
Type: Bottom
Resources
- 0PF20L 0PF20R 0PF10L 0PF10R Template
- CRL Stainless Steel Disclaimer
- Commercial Patch Hardware European Series System CAD Drawings.dwg
- Commercial Patch Hardware European Series System CAD Drawings.pdf
- Commercial Patch Hardware North American Series System CAD Drawings.dwg
- Commercial Patch Hardware North American Series System CAD Drawings.pdf
- Commercial Patch Hardware Wedge Lock 3-8 inch Glass to 1-2 inch Glass System CAD Drawings.dwg
- Commercial Patch Hardware Wedge Lock 3-8 inch Glass to 1-2 inch Glass System CAD Drawings.pdf
- Commercial Patch Hardware Wedge Lock 5-8 inch Glass to 3-4 inch Glass System CAD Drawings.dwg
- Commercial Patch Hardware Wedge Lock 5-8 inch Glass to 3-4 inch Glass System CAD Drawings.pdf
- Glass Fabrication Details OFP1020 AVD3859A3.pdf
