Description
PHI 2110-VI-V4908A-LHRB-630-36 Rim Exit Device, Inside Lock Down, Visual Indicator, Vandal Resistant Lever, 36in
Precision Hardware PHI 2110-VI-V4908A-LHRB-630-36 Rim Exit Device combines robust security features with user-friendly operation. Designed for heavy-duty applications, this Grade 1 exit device is built to withstand high traffic environments, making it ideal for healthcare and educational facilities. Its investment cast construction and vandal-resistant trim ensure maximum protection against forced entry while allowing for easy egress. The device features an inside lockdown mechanism and a visual indicator for enhanced functionality. Its key locking/unlocking system paired with a vandal-resistant lever and escutcheon plate trim adds an extra layer of security. With a sleek design including no exposed fasteners, it seamlessly blends with any architectural aesthetic. The device is 36 inches in length and accommodates standard door thicknesses of 1-3/4″ to 2-1/4″. Precision Engineering reduces maintenance needs, thanks to fewer moving components and a built-in rubber bumper sound dampener that minimizes noise in busy areas. The device is also field reversible and allows for easy retrofit on existing doors, making installation straightforward. Available in a satin stainless steel finish, the PHI 2110 delivers both style and performance for any exit situation.
Rim Exit Device with Inside Lock Down Feature and Visual Indicator, Key Locks/Unlocks Vandal Resistant Lever x Escutcheon Plate Trim, Left Hand Reverse, Less Rim Cylinders for Trim and Lock Down, No Dogging, 36in, Grade 1, 630/US32D Stainless Steel
Notice: The info below is not item specific.
The 2000 exit devices have earned a reputation for strength in every situation—performing in even the most abusive applications. Thanks to its efficient engineering and durable hardware, the Precision 2000 represents the ultimate in safety, security and simplicity. No other exit device offers the level of functionality and dependability as this grade 1, heavy-duty exit device. Built with fewer components and in various door configurations, it provides smoother operation with minimal need for maintenance. The durable construction allows it to withstand high traffic and high use on a regular basis, making it particularly attractive for healthcare and education buildings. These combined benefits give it a longer life span and a lower overall cost of ownership.
Features:
- Maximum protection: Investment cast construction and vandal-resistant trim deliver maximum protection against forced entry without impeding easy exit.
- Dependable operation: The 2000 allows fast, easy egress. A built-in rubber bumper sound dampener reduces noise even in high traffic areas. Designed with fewer moving components, the 2000 requires much lower maintenance than comparable products.
- Smooth appearance: We designed the 2000 for a smooth appearance—no exposed fasteners and very low-profile end caps—that won’t pinch, catch or snag during operation. Available in a range of true architectural finishes, the 2000 fits any design aesthetic.
- Premium materials and construction: Made from top-quality materials and with hardened steel hex dogging assembly, the 2000 delivers durable, low maintenance performance.
- Flexible installation: Universal-function 2000 exit devices are field reversible and available to fit a range of door sizes and types. The wide stile design allows for installation on doors that are not completely flat or when vision lites or glass project beyond the door. No shims or glass cutting is required for installation.
- Easy retrofit: Universal mounting holes and flexible configuration options make installing 2000 series exit devices on existing doors simple.
- Indoor/outdoor application: Available in 626W weatherized finish, 2000 series exit devices can withstand even the harshest environmental conditions.
Specifications:
- Certifications: BHMA A156.3 Grade 1 listed ANSI A117.1 accessibility code (ADA) compliant
- Materials:
- Exit device body: heavy-duty solid brass, bronze, aluminum and stainless steel
- Chassis: investment cast steel, zinc dichromated
- Chassis cover: stainless steel, brass or bronze
- Latchbolt: stainless steel, deadlocking, 3/4″ throw
- Door Dimensions:
- Thickness: 1-3/4″ – 2-1/4″ standard
- Height: 6’8″ – 10’ (200 series)
- Width: 3′ – 4′
- Strikes:
- S300: Investment cast stainless steel, black powder coated
- S988: Optional strike for use on aluminum door applications
- S458: Optional strike for use on mullion applications
- Device Types:
- Wide rim
- Narrow rim
- Concealed vertical rod
- Narrow stile concealed vertical rod
- Surface vertical Rod
- Wood door concealed vertical rod
- Mortise
- Electrified Options:
- C: Pre-terminated quick connect plug
- DE: Delayed egress
- E: Electric lock/unlock
- ELR: Electric latch retraction
- MLR: Motorized latch retraction
- LS: Latchbolt monitoring switch
- Q: Wireless access management system
- TS: Touchbar monitoring switch
- WTS: Weatherized touchbar switch
- ALK: Battery powered alarm
- ALW: Hardwired alarm
- DS: Door position switch
- WALW: Weatherized alarm
- Trim and Lever Styles:
- Vandal Resistant Lever–no lever reset required
- Knob Trims
- Pull Trims
- A, B, C or D lever styles, standard
- 20 available decorative lever styles
Finishes:
- 605 – Bright brass
- 606 – Satin brass
- 612 – Satin bronze
- 613 – Oil-rubbed bronze
- 622 – Powder coated black
- 625 – Bright chrome
- 626W – Satin chrome weatherized
- 628 – Satin aluminum, clear anodized
- 630 – Satin stainless steel
- 690 – Dark bronze
Attributes
Alternate Codes: 2110-V4908A-VI-LHRB-630-36, 2110V4908AVILHRB63036, 2110-VI-V4908A-LHRB-630-36, 2110VIV4908ALHRB63036, PHG2110-V4908A-VI-LHRB-630-36
Category: Panic Devices, Panic Devices & Exit Alarms, Rim Panic Devices
