Sargent LC-706-ETL-BSP LHR Storeroom Exit Trim, Less 41 Mortise Cylinder, L Lever, LHR, Black Suede
Sargent LC-706-ETL-BSP LHR Storeroom offers a robust solution for secure access management in storerooms. Designed with functionality in mind, this exit trim features a convenient lever handle that allows for easy one-handed operation. The trim functions with a key that unlocks the exit trim and automatically relocks when the key is removed, ensuring enhanced security for your space. Finished in a durable black suede powder coat, the LC-706-ETL-BSP is built to withstand the rigors of daily use while providing a sleek, modern appearance. This model is a left-hand reverse (LHR) configuration and is designed to work seamlessly with Sargent’s 8706 exit device. The trim is through bolted to the chassis, which increases security and durability. Compatible with various functions, including key retracts latch and passage only modes, this exit trim can be tailored to meet your specific needs. The stainless steel levers option is available for those seeking added strength and longevity. With ANSI/BHMA finishes, the Sargent LC-706-ETL-BSP LHR Storeroom is not just a practical choice but also an aesthetically pleasing addition to any door in need of reliable security.
Storeroom (Key Unlocks Exit Trim, Relocks When Key is Removed), Less 41 Mortise Cylinder, Escutcheon with L Lever, LHR Left Hand Reverse, BSP Black Suede Powder Coat (Works with 8706)
Notice: The info below is not item specific.
The 700 series ET control is sold separately from the exit device and can be used with 8888 & 8810 exit device. The trim is non handed and is through bolted to the chassis for greater security and durability. Available in 7 functions and Sargent studio, coastal and standard lever designs to accommodate most requirements.
Features:
- ANSI/BHMA Finishes
- Easy operating lever handle allows convenient one hand operation
- ET trim is not available in 32 or 32D
- Stainless steel levers are available
Functions:
- 04: Key retracts latch #34 cylinder supplied. ANSI 03
- 10: No O/S operation or cylinder (pull only). ANSI 02
- 28: Passage only (no cylinder). ANSI 15
- 63: Key outside unlocks/locks thumbpiece #34 cylinder supplied. ANSI 05
- 62: Key unlocks thumbpiece, thumbpiece retracts latch/thumbpiece relocks when key is removed #34 cylinder supplied. ANSI 06
- 66: Key outside retracts latch; key inside unlocks/locks O/S trim O/S #34 and I/S #44. ANSI 07
- 73: Electrified ET trim – fail safe power off, unlocks lever (no cylinder)
- 74: Electrified ET trim – fail secure power off, locks lever (no cylinder)
- 75: Electrified ET trim – fail safe power off, unlocks lever, key retracts latch #34 cylinder supplied
- 76: Electrified ET trim – fail secure power off, locks lever, key retracts latch #34 cylinder supplied
Finishes:
- 0-3/605 – Bright brass, clear coated
- 0-4/606 – Satin brass, clear coated
- 0-9/611 – Bright bronze, clear coated
- 1-0/612 – Satin bronze, clear coated
- 10B/613 – Dark oxidized satin bronze, oil rubbed
- 10BE/613E – Dark oxidized satin bronze, equivalent
- 10BL/613L – Dark oxidized satin bronze clear coated
- 20D/624 – Dark statuary bronze lacquered
- 2-6/625 – Bright chrome plated
- 26D/626 – Satin chrome plated
- 3-2/629 – Bright stainless steel
- 32D/630 – Satin stainless steel
- BSP – Black suede powder coat
- WSP – White suede powder coat
Attributes
Alternate Codes: LC-706-ETL-BSP LHR, LC706ETLBSPLHR
Category: Panic Devices & Exit Alarms, Panic Device Trims
Cylinder Type: Less Cylinder
Door Application: Panic Devices & Exit Alarms
Door Thickness: 1-3/4″
Finish Code: BSP
Finish Color: Black Suede Powder Coat
Handing: Left Handed Reverse
