Description
Sargent LC-706-8-ETL-BSP LHR Storeroom Exit Trim, Key Unlocks, Relocks, L Lever, LHR, Black Suede Finish
Sargent LC-706-8-ETL-BSP LHR Storeroom offers a sophisticated solution for securing storerooms with its innovative design and robust functionality. This exit trim features a lever handle that allows for convenient one-hand operation, ensuring ease of use in high-traffic environments. Designed for left-hand reverse applications, it is compatible with a variety of Sargent exit devices, making it a versatile choice for different setups. The LC-706 is constructed with durability in mind, as it is through-bolted to the chassis, providing enhanced security. This trim functions effectively with a key that unlocks the exit trim and relocks when removed, offering superior control over access. It is designed for doors with a thickness of 1-3/4″ and comes in an attractive black suede powder coat finish (BSP) that complements any decor. Available in multiple functions-including key retracts latch, passage only, and electrified trim options-the LC-706 caters to a wide range of security needs. Whether you’re looking for a reliable panic device or an exit alarm, this trim meets ANSI/BHMA standards and is an excellent choice for both professionals and discerning homeowners alike. Elevate your security with Sargent’s trusted craftsmanship.
Storeroom (Key Unlocks Exit Trim, Relocks When Key is Removed), Less 41 Mortise Cylinder, Escutcheon with L Lever, LHR Left Hand Reverse, BSP Black Suede Powder Coat (Works with NB/SP/PR8706, 8806, 8888, 8906)
Notice: The info below is not item specific.
The 700 series ET control is sold separately from the exit device and can be used with 8888 & 8810 exit device. The trim is non handed and is through bolted to the chassis for greater security and durability. Available in 7 functions and Sargent studio, coastal and standard lever designs to accommodate most requirements.
Features:
- ANSI/BHMA Finishes
- Easy operating lever handle allows convenient one hand operation
- ET trim is not available in 32 or 32D
- Stainless steel levers are available
Functions:
- 04: Key retracts latch #34 cylinder supplied. ANSI 03
- 10: No O/S operation or cylinder (pull only). ANSI 02
- 28: Passage only (no cylinder). ANSI 15
- 63: Key outside unlocks/locks thumbpiece #34 cylinder supplied. ANSI 05
- 62: Key unlocks thumbpiece, thumbpiece retracts latch/thumbpiece relocks when key is removed #34 cylinder supplied. ANSI 06
- 66: Key outside retracts latch; key inside unlocks/locks O/S trim O/S #34 and I/S #44. ANSI 07
- 73: Electrified ET trim – fail safe power off, unlocks lever (no cylinder)
- 74: Electrified ET trim – fail secure power off, locks lever (no cylinder)
- 75: Electrified ET trim – fail safe power off, unlocks lever, key retracts latch #34 cylinder supplied
- 76: Electrified ET trim – fail secure power off, locks lever, key retracts latch #34 cylinder supplied
Finishes:
- 0-3/605 – Bright brass, clear coated
- 0-4/606 – Satin brass, clear coated
- 0-9/611 – Bright bronze, clear coated
- 1-0/612 – Satin bronze, clear coated
- 10B/613 – Dark oxidized satin bronze, oil rubbed
- 10BE/613E – Dark oxidized satin bronze, equivalent
- 10BL/613L – Dark oxidized satin bronze clear coated
- 20D/624 – Dark statuary bronze lacquered
- 2-6/625 – Bright chrome plated
- 26D/626 – Satin chrome plated
- 3-2/629 – Bright stainless steel
- 32D/630 – Satin stainless steel
- BSP – Black suede powder coat
- WSP – White suede powder coat
Attributes
Alternate Codes: LC-706-8-ETL-BSP LHR, LC7068ETLBSPLHR
Category: Panic Devices & Exit Alarms, Panic Device Trims
Cylinder Type: Less Cylinder
Door Application: Panic Devices & Exit Alarms
Door Thickness: 1-3/4″
Finish Code: BSP
Finish Color: Black Suede Powder Coat
Handing: Left Handed Reverse
