Description
Sargent LC-706-4-ETJ-26D LHR Storeroom Exit Trim, Key Unlocks, Relocks, Less 41 Cylinder, Satin Chrome
Sargent LC-706-4-ETJ-26D LHR Storeroom is designed for both security and ease of use, making it an ideal choice for panic devices and exit alarms. This exit trim features a lever handle that allows for convenient one-handed operation, enhancing accessibility in busy environments. The unit operates with a key that unlocks the exit trim and automatically relocks when the key is removed, providing added security. Constructed with durability in mind, the trim is through-bolted to the chassis. It accommodates a variety of functions, including key retracts and passage-only options, to suit diverse security needs. The satin chrome finish (626/US26D) not only offers a modern aesthetic but also ensures resilience against wear and tear. This model is compatible with Sargent’s AD8406, MD8406, AD8606, and MD8606 exit devices, enhancing its versatility. It is also available in several additional finishes, including bright brass and dark oxidized satin bronze, allowing for customization to match any decor. With a door thickness capability of 1-3/4″, the Sargent LC-706-4-ETJ-26D LHR is a reliable choice for professionals seeking a robust and functional security solution.
Storeroom (Key Unlocks Exit Trim, Relocks When Key is Removed), Less 41 Mortise Cylinder, Escutcheon with J Lever, LHR Left Hand Reverse, 626/US26D Satin Chrome (Works with AD8406, MD8406, AD8606, MD8606)
Notice: The info below is not item specific.
The 700 series ET control is sold separately from the exit device and can be used with 8888 & 8810 exit device. The trim is non handed and is through bolted to the chassis for greater security and durability. Available in 7 functions and Sargent studio, coastal and standard lever designs to accommodate most requirements.
Features:
- ANSI/BHMA Finishes
- Easy operating lever handle allows convenient one hand operation
- ET trim is not available in 32 or 32D
- Stainless steel levers are available
Functions:
- 04: Key retracts latch #34 cylinder supplied. ANSI 03
- 10: No O/S operation or cylinder (pull only). ANSI 02
- 28: Passage only (no cylinder). ANSI 15
- 63: Key outside unlocks/locks thumbpiece #34 cylinder supplied. ANSI 05
- 62: Key unlocks thumbpiece, thumbpiece retracts latch/thumbpiece relocks when key is removed #34 cylinder supplied. ANSI 06
- 66: Key outside retracts latch; key inside unlocks/locks O/S trim O/S #34 and I/S #44. ANSI 07
- 73: Electrified ET trim – fail safe power off, unlocks lever (no cylinder)
- 74: Electrified ET trim – fail secure power off, locks lever (no cylinder)
- 75: Electrified ET trim – fail safe power off, unlocks lever, key retracts latch #34 cylinder supplied
- 76: Electrified ET trim – fail secure power off, locks lever, key retracts latch #34 cylinder supplied
Finishes:
- 0-3/605 – Bright brass, clear coated
- 0-4/606 – Satin brass, clear coated
- 0-9/611 – Bright bronze, clear coated
- 1-0/612 – Satin bronze, clear coated
- 10B/613 – Dark oxidized satin bronze, oil rubbed
- 10BE/613E – Dark oxidized satin bronze, equivalent
- 10BL/613L – Dark oxidized satin bronze clear coated
- 20D/624 – Dark statuary bronze lacquered
- 2-6/625 – Bright chrome plated
- 26D/626 – Satin chrome plated
- 3-2/629 – Bright stainless steel
- 32D/630 – Satin stainless steel
- BSP – Black suede powder coat
- WSP – White suede powder coat
Attributes
Alternate Codes: LC-706-4-ETJ-26D LHR, LC7064ETJ26DLHR
Category: Panic Devices & Exit Alarms, Panic Device Trims
Cylinder Type: Less Cylinder
Door Application: Panic Devices & Exit Alarms
Door Thickness: 1-3/4″
Finish Code: 626
Finish Color: Brushed Chrome, Satin Chrome
Handing: Left Handed Reverse
