CRL CM12X28SA Satin Anodized 12″x28″ Back-to-Back Push-Pull Handle Set
C.R. Laurence CM12X28SA Satin Anodized 12″ x 28″ Back-to-Back Straight Combination Push and Pull Handle Set offers an elegant solution for modern glass installations. Designed for use with monolithic tempered glass ranging from 3/8″ to 3/4″ (10 to 19 mm) in thickness, this handle set is constructed from sturdy 1″ (25 mm) diameter stainless steel or brass tubing, ensuring durability and a polished aesthetic. Available in five attractive architectural finishes, the CM12X28SA not only enhances the visual appeal of your space but also provides reliable functionality. The set includes comprehensive mounting hardware, featuring through-bolts for glass mounting and matching finish metal washers along with rubber gaskets for a seamless installation. For precise installation, the handle set requires three 5/8″ (16 mm) diameter holes with various center-to-center configurations, allowing flexibility for different applications. The pull mounting center-to-center measures 12″ (305 mm), while the push mounting center-to-center measures 28″ (711 mm), making it suitable for high-traffic areas. Elevate your architectural designs with the C.R. Laurence CM12X28SA, a blend of style and practicality for any building professional or discerning homeowner.
Satin Anodized 12″ x 28″ Back-to-Back Straight Combination Push and Pull Handle Set
- For Use with 3/8″ to 3/4″ (10 to 19 mm) Glass
- 1″ (25.4 mm) Diameter Stainless Steel or Brass Tubing
- Five Beautiful Architectural Finishes
- Use Monolithic Tempered Glass
This
CRL Glass Mounted Straight Push/Pull Handle Combination is available in two different sizes and many attractive architectural finishes.
SPECIFICATIONS:
For Use With: 3/8″ to 3/4″ (10 to 19 mm) Glass
Construction: 1″ (25 mm) Diameter
Stainless Steel or Brass Tubing
Glass Fabrication Required:
Three 5/8″ (16 mm) Diameter Holes,
10″ (254 mm) Center-to-Center
12″ (305 mm) Center-to-Center
28″ (711 mm) Center-to-Center
33″ (838 mm) Center-to-Center
Offset: 3″ (76 mm) Center-to-Center
Optional 1-1/4″ (32 mm) Diameter
Available on Special Order
INCLUDES:
2 Each: Through-Bolts for Glass Mounting
4 Each: 1-1/4″ (32 mm) Diameter Matching Finish Metal Washers and Rubber Gaskets
Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer’s video card and on how your monitor’s color is adjusted.
Attributes
Compliance and Restrictions: Warning Reproductive Harm – www.p65warnings.ca.gov
Diameter: 1 in. (25 mm)
Finish/ Color:: Satin Anodized
Glazing Thickness: 3/8 in. To 3/4 in. (10 mm To 19 mm)
Mounting Hole Diameter: 5/8 in. (16 mm)
Mounting Type: Back-to-Back
Pull Mounting Center To Center: 12 in. (305 mm)
Push Mounting Center To Center: 28 in. (711 mm)
Shipping Limitations: None
Style Washer Diameter: 1-1/4 in. (32 mm)
Style Washers: Yes
