Description
Schlage F51A CHP 619 KD F-Series Entry Lock Instructions
Schlage Residential F51A CHP 619 KD F-Series Entry Lock combines style and functionality to enhance your home’s security. Featuring a sophisticated champagne lever and a sleek satin nickel finish, this entry lock seamlessly integrates with various residential decors, from classic to contemporary.Designed for ease of use, the F51A lock offers a straightforward 3-step installation process that requires only a screwdriver, making it a perfect choice for both professionals and DIY enthusiasts. This lock is suitable for residential single- and multi-family doors, ensuring versatility across your property. The F51A meets the ANSI A156.2, 1996, Series 4000 Grade 2 certification, providing reliable security. Additionally, it is U.L. listed for use on fire doors rated for up to three hours, adding an extra layer of safety. It accommodates standard door thicknesses from 1-3/8″ to 1-3/4″, and the universal latch fits both 2-3/8″ and 2-3/4″ backsets, with a 5″ option available. ADA compliant, this lock not only meets accessibility standards but also offers a conventional cylinder type for secure key access. Upgrade your home’s entryway with the Schlage F51A CHP 619 KD F-Series Entry Lock, an elegant solution that prioritizes both aesthetics and security.
F-Series Entry Lock
Entry Lock, Champagne Lever, Satin Nickel
From classic looks that never go out of style to bold contemporary designs, Schlage’s levers and door handles fit and accentuate virtually any decor. Available in a variety of functions, you can choose the perfect look for every room in your house – it’s the easiest way to give your entire home a style upgrade.
Easy 3-step installation, only a screwdriver needed.
Schlage’s F Series designs range from bold to classic to match any residential décor. Plus, it features an easy 3-step installation, only a screwdriver needed.
- Applications: Residential single- and multi-family doors
- Certifications: ANSI A156.2, 1996, Series 4000 Grade 2
- U.L. Listed: Locks for up to three-hour fire doors available
- Door thickness range: 1-3/8″ to 1-3/4″ (35mm-44mm) standard
- Backset: Universal latch standard, fits either 2-3/8″ (60mm) or 2-3/4″ (70mm) backsets. 5″ (127mm) backset available
- ADA compliant: Yes
Attributes
Manufacturer surcharge: 6.5%
Base Material: Brass or Bronze
Cylinder Type: Conventional Cylinder
Door Thickness: 1-3/8 In. – 1-3/4 In.
Finish: 619/US15
Function: F51A-Keyed Entry
Grade: Grade 2
Leverknob Design: CHP – Champagne
Pack Qty: 1
Series: F Series Residential Levers
Std Keyway: C
Subtype: Tubular Lock
Type: Locks, Cylinders, Cores, Keyblanks
Unit of Measure: Each
Resources
- BE365, FE575, FE595 – Keypad Locks Programming Guide
- BE365, FE575, FE595 – Keypad Locks User Guide
- F Series Residential Levers Cut Sheet
- F10/F40/F51 – F Series Knobs & Levers Installation Instructions
- FA10/FA40/FA51 – FA Series Installation Instructions
- FA170 – Non-turning Lever Installation Instructions
- FE10 – Passage Lever with Built-In Alarm Installation Instructions
- FE575, FE595 – Keypad Entry Door Preparation Instructions For Door With Existing Holes
- FE576 – Keypad Lock with Built-In Alarm and Auto-Lock Installation Instructions
- FE576, FE596 – Keypad Entry with Built-In Alarm User’s Guide
- Installing Your FE575 Keypad Entry Lock
- Installing Your FE595 Keypad Entry Lock
- Mechanical Key Override for FE575 and FE595
- Schlage Control Smart Interconnected Door Prep No Holes – FE410F
- Schlage Control Smart Locks User Guide
- Schlage Control Smart-Interconnected Door Prep Existing Holes – FE410F
- Von Duprin Finishes Chart
