Schlage ND96LDEU SPA 605 RX Gr1 Vandlgard Storage Fail-Safe Instructions
Schlage ND96LDEU SPA 605 RX Gr1 Vandlgard Storerm, Fail Sec is a Grade 1 electrified cylindrical lock designed for enhanced security in storeroom applications. This lock features a storeroom function with a Vandlgard mechanism, ensuring safe and reliable access control. Operating on a 12-24V DC system, it is fail secure, making it ideal for high-security environments. The ND Series locks are UL Listed, providing peace of mind for high traffic areas where continuous operation is essential. The lock’s auto-detecting input allows for seamless integration into existing access control systems, while the low 0.23 amp maximum current draw permits multiple locks to operate efficiently on a single power supply. Additionally, the low holding current of 0.010 amp prevents hot levers in electrically locked applications. With its sturdy brass construction and a striking bright brass finish, this lock not only delivers functionality but also adds a touch of elegance. It is compatible with door thicknesses ranging from 1-3/4″ to 2″ and features a modular Request to Exit (RX) that can be added at any time. Whether for new constructions or retrofits, the Schlage ND96LDEU ensures both security and convenience.
Gr1 Vandlgard Storerm,Fail Sec
Grade 1 Electrified Cylindrical Lock, Storeroom Function with Vandlgard, 12-24V DC, Fail Secure, 2-3/4″ Backset, RX, Sparta Lever, Less Cylinder, Bright Brass
ND Series locks are available for electrically locking and unlocking controls for high security and fire safety applications.They are UL Listed and rated for both fire and electrical single-point locking on labeled doors. RX feature is available on ND10, ND12, ND80 and ND96 families. Switch is ready to be used in a normally open or normally closed application.
Electrified Schlage cylindrical locks offer superior energy efficiency and flexibility in wired electrified applications.
Wired electrified locks complement the mechanical offering and are typically incorporated into a wired access control system or used independently with a remote access switch.
Applications
The electrified ND is ideally used in:
- High traffic areas, where line power ensures continuous operation
- New construction, where electrified door prep, hinges and wiring can easily be incorporated into the building
Key Features
All mechanical features plus:
- Auto-detecting 12-24VDC input
- Selectable EL/EU operation
- Low 0.23 amp max current draw that allows multiple locks on a single power supply
- Low 0.010 amp holding current that eliminates “hot levers” in electrically locked applications
- Modular Request to Exit (RX) that can be added at any time
- Inventory friendly–one lock supports 12-24V, EL or EU, with or without RX
- Six electrified functions for application flexibility
Attributes
Manufacturer surcharge: 4.5%
Amp Draw: 0.23
Application: Storeroom Lever
Baa Qualified: Yes
Base Material: Brass
Commercial Residential: Commercial
Country of origin: Mexico
Cylinder Type: Less Cylinder
Door Thickness: 1-3/4″ to 2″
Dust Box: None
Finish: 605/US3
Function: 96EU-Fail Secure
Grade: Grade 1
Installation: Commercial
Latch Backset Dim: 2-3/4″
Leverknob Design: SPA – Sparta
Limited Warranty: 1 Year
Lock Face Size: 2-1/4″ X 1-1/8″
Operating Voltage: 12VDC/24VDC
Origin: Mexico
Pack Height 2: 10″
Pack Length 2: 16.38″
Pack Qty: 1
Pack Width 2: 14.63″
Pbs Options: ‘193321402,4541275,4541421
Power: Hard Wired
Product Height: 4.75″
Product Length: 9.5″
Product Width: 8.25″
Roseescutcheon Design: 3-7/16″ Diameter
Screws: Combination
Series: ND Series Electrified Lever Locks
Ship Weight: 5 lbs.
Std Latch Number: 14-047
Std Latch Type: Guarded Latch
Std Strike Height: 4-7/8″
Std Strike Number: 10-025
Std Strike Type: ASA
Std Strike Width: 1-1/4″
Subtype: Electric Cylindrical Lock
Switch Type: RX
Type: Electric Locks
