Description
Schlage HL6-2 626 E2 Hospital Latch 2.75″ BS ENGRAV
Schlage HL6-2 626 E2 Hospital Latch is designed specifically for healthcare environments, featuring a passage function and a 2-3/4″ backset that ensures ease of access in busy settings. The T-Square corner strike and engraved “PUSH” and “PULL” indicators enhance usability, making it ideal for situations where hands may be occupied. The satin chrome finish not only adds a modern touch but also ensures durability in high-traffic areas. The HL Series excels in reducing operational noise, a critical feature in hospitals and institutional settings where quiet is paramount. This latch offers a dampened paddle action that significantly minimizes noise during use, proving to be 50% quieter than previous models. This improvement aids in creating a serene environment for patients and staff alike. With applications ranging from patient rooms to busy hallways, this latch meets the demands of various healthcare settings by providing reliable performance and easy operation. The HL6-2 latch is suitable for doors with a thickness of 1-3/4 inches and is designed for commercial installation. Choose Schlage HL6-2 for a solution that prioritizes functionality, noise reduction, and enhanced accessibility in crucial environments.
HOSPITAL LATCH 2 3/4 BS ENGRAV
Hospital Push/Pull Tubular Latch, Passage Function, 2-3/4″ Backset, T-Square Corner Strike, Push up Pull up Engraving, Spring Latch (Unguarded), Satin Chrome
Push/Pull Latch, 2-3/4″ Backset, Engraved, “PUSH” Up, “PULL” Up, Satin Chrome
Quiet hospital push/pull hardware.
The HL Series includes a full line of push/pull hardware that is ideal forhealthcare and other institutional applications where ease of operation isneeded – even when hands are not free.Delivering both superior quality and exceptional performance, the HL Seriesoffers a wide variety of popular finishes and configurations providing theflexibility needed to meet the most demanding door control applications.
Hospitals and other healthcare environments have special requirements fornoise reduction to help patients heal faster and staff perform moreaccurately and efficiently.There are many sources of noise, but choosing quiet door hardware can helpreduce excess noise and create quieter environments. The newly redesignedHL Series quiet hospital push/pull hardware offers a proven 50% quieterpaddle operation than our previous product, providing healthcareorganizations a reliable solution for noise reduction initiatives.
- Dampened paddle action – depression and snap back – reduces noiseassociated with hardware operation
- Proven 50% quieter paddle operation – both in the pull and pushdirection – than our previous solution
- Comes standard on all HL Series hardware
Applications
Anywhere operational noise is disruptive:
- Healthcare areas where patients are sleeping and healing
- Work spaces where concentration is important
- Busy traffic areas such as hallways
- Chapels or auditoriums where noise can be disturbing
- Office or administrative areas
Attributes
Manufacturer surcharge: 4.5%
Bolt Projection: 1/2 In.
Commercial Residential: Commercial
Door Thickness: 1-3/4 In.
Dust Box: None
Finish: 626/US26D
Function: HL6-Passage
Installation: Commercial
Leverknob Design: Engraved – “PUSH” up, “PULL” up
Lock Face Size: 2-1/4 In. x 1-1/8 In.
Pack Qty: 1
Pbs Options: 198928251
Series: HL Series Hospital Latches
Std Latch Backset Dim: 2-3/4 In.
Std Latch Number: 800108
Std Latch Type: Spring Latch (Unguarded)
Std Strike Height: 2-3/4 In.
Std Strike Number: 890023
Std Strike Type: T-Square Corner
Std Strike Width: 1-1/8 In.
Subtype: Hospital Push/Pull Latch
Type: Locks, Cylinders, Cores, Keyblanks
Unit of Measure: Each
Resources
- HL Series Hospital Latches Cut Sheet
- Von Duprin Finishes Chart
