Description
Schlage L463B 606 RH Single Cylinder Mortise Deadbolt
Schlage L463B 606 RH Single Cyl Mortise Deadbolt offers robust security with its Grade 1 certification, making it an ideal choice for commercial applications where safety is a priority. This small-case mortise deadbolt features a cylinder x cylinder thumbturn design, ensuring ease of operation while maintaining high security. The satin brass finish not only enhances aesthetic appeal but also adds durability against wear. Designed specifically for primary locking applications, this deadbolt excels in environments where no latching is required, such as restrooms and utility spaces. Additionally, it serves effectively as an auxiliary lock in various settings. The L400 Series offers six available functions and is compatible with a range of finishes, allowing for customization. Key specifications include a 1″ stainless steel throw deadbolt and a deeper retainer groove in the cylinder shell, increasing resistance to wrenching and pullout. The 7-pin SFIC prep less core ensures backward compatibility with existing systems. With a fire rating of 3 hours and corrosion-resistant steel components, the Schlage L463B is built for longevity and reliability. This versatile deadbolt is packed with security features, making it a smart choice for demanding environments.
Single Cyl Mortise Deadbolt
Grade 1 Classroom Small Case Mortise Deadbolt, Cylinder x Cylinder Thumbturn, 7-Pin SFIC Prep Less Core, Satin Brass Finish, Right-Handed
L400 Series locks are designed for use as primary locks where no latching is required, such as restrooms and small doors to utility spaces. It also offers optimum security when used as an auxiliary lock in other applications.
Designed for use as primary locks where no latching is required.
The L400 Seriesoffers optimum security when used as an auxiliary lock in other applications.
- Six available functions
- 12 finishes
- 1″ (25 mm) stainless steel throw deadbolt
- Deeper retainer groove in cylinder shell increases security against wrenching and pullout; all cylinders backward compatible
- 6-pin Everest® 29 cylinder with patented keys standard
- Steel case and parts are corrosion resistant
Attributes
Manufacturer surcharge: 4.5%
Ansi: ANSI/BHMA A156.36-2010, Grade 1
Ansi Function: E06091
Bolt Projection: 1″
Cam Number: L583-255
Cam Type: Schlage L
Case Dimensions: 4-7/16″ x 3-5/8″ x 1″
Commercial Residential: Commercial
Cylinder Length: 1-3/8″
Cylinder Type: Schlage 7-Pin SFIC Prep Less Core
Door Thickness: 1-3/4″
Dust Box: Plastic
Faceplate Size: 5-9/16″ x 1-1/4″
Finish: 606/US4
Finish Family: Matte Brass
Fire Rated: Yes
Fire Rating: 3 Hours {A}
Function: 463-Cylinder x Cylinder Thumbturn
Function Family: Classroom
Grade: Grade 1
Handing: Right-Handed
Installation: Commercial
Latch Backset Dim: 2-3/4″
Limited Warranty: 3 Years
Lock Face Size: 5-9/16 ” x 1-1/4″
Pack Height: 3″
Pack Length: 6.5″
Pack Qty: 1
Pack Width: 5.75″
Pins: 7
Screws: Combination
Series: L400 Series Mortise Deadbolts
Ship Weight: 3 lbs.
Std Latch Backset Dim: 2-3/4″
Std Latch Number: L283-003
Std Latch Type: Deadbolt
Std Strike Height: 3-1/2″
Std Strike Number: 10-079
Std Strike Type: Flat
Std Strike Width: 1-1/8″
Subtype: Mortise Deadbolt Only
Type: Locks, Cylinders, Cores, Keyblanks
Ul Listing: UL/cUL Listed
Unit of Measure: Each
Resources
- L9000 Series Mortise Lock Cut Sheet
- Von Duprin Finishes Chart
