Description
Schlage B560J 622 OS-LOC IS-LOC Single Cylinder Deadbolt
Schlage B560J 622 OS-LOC IS-LOC Single Cylinder Deadbolt combines robust security with versatile functionality, making it an ideal choice for both commercial and residential applications. This Grade 2 deadbolt features a keyed exterior and a thumbturn interior, ensuring easy access while maintaining high security. Designed with locksmiths in mind, the B500 Series accommodates all Schlage cylinder formats and fits a wide range of door thicknesses from 1-3/8″ to 1-7/8″. Its adjustable backset and lock-in-place helix design enhance installation flexibility. The integrated anti-pry shield and thicker metal security strike bolster defense against unauthorized entry, while the third screw in the strike plate allows for deeper anchoring. This model also includes a dual indicator showing “UNLOCKED/LOCKED” status, ensuring you always know your door’s security status at a glance. The large, ADA-compliant thumbturn facilitates ease of use, even in high-traffic areas. With a matte black finish, the B560J adds a modern touch to any door. Backed by a 3-year limited warranty and meeting UL 10B and UL 10C requirements, the Schlage B560J is a reliable choice for those seeking enhanced security without compromising on style or functionality.
Single Cylinder Deadbolt
Grade 2 Single Cylinder Deadbolt, Keyed Outside/Thumbturn Inside, FSIC Prep, Less Core, Dual Indicator “UNLOCKED/LOCKED”, 12-288 Latch, 10-094 Strike, 1-3/8″ – 1-7/8″ Door Thickness, Matte Black Finish
The B500 Series deadbolt from Schlage offers some of thetoughest, most versatile Grade 2 deadbolts in the business.Designed by locksmiths for locksmiths, B500 Series can acceptevery Schlage cylinder format and fit virtually every door youservice. It features enhanced lock strength on the jamb side ofthe door and is offered in most functions with optional single- ordual-sided lock status indicator trim options. Large window sizeand SchlageÂs patented 180-degree visibility will change foreverthe way you look at deadbolts.
A revolutionary new deadbolt that delivers higher security and tougher performance.
Designed by locksmiths for locksmiths, the B500 Series deadbolt can be fitted with any Schlage cylinder, fits virtually every door you service, enhances lock strength on the jamb side of the door and will change forever the way you look at deadbolts.
- Adjustable backset with lock-in-place helix design
- Integrated anti-pry shield protects latch
- Thicker metal security strike back-up on jamb side
- Security strike on jamb has third screw for stronger, deeper anchoring
- Added space inside strike box for true deadlatch
- Seamless steel latch construction along the entire length of the bolt housing
- 10% larger diameter deadbolt
- Zinc bolt with spinning hardened steel pin inside
- Tapered front housing that can’t be unscrewed
- Integrated trim piece for fewer pieces out of the box
- Large, easy-to-use, ADA compliant thumbturn
- Meets UL 10B andd UL 10C requirements
Attributes
Manufacturer surcharge: 4.5%
Ansi: A156.36, 2010
Ansi Function: E0152 – Single Cylinder Deadbolt
Application: Indicator with Text
Baa Qualified: Yes
Bolt Projection: 1″
Commercial Residential: Commercial
Country of origin: USA
Cylinder Type: FSIC Prep, Less Core
Door Thickness: 1-3/8″ – 1-7/8″
Dust Box: Metal
Finish: 622/US19
Finish Family: Black
Grade: Grade 2
Installation: Commercial
Keying: Keyed
Limited Warranty: 3 Years
Lock Face Size: 1″ x 2-1/4″
Mechanical Option: Keyed Outside x Thumbturn Inside
Of Keys: 2
Origin: USA
Pack Qty: 1
Product Height: 4.13″
Product Length: 3.57″
Product Width: 2.54″
Series: B500 Series Deadbolts
Std Latch Backset Dim: Adjustable for 2-3/8″ or 2-3/4″
Std Latch Number: 12-288
Std Latch Type: Square Corner
Std Strike Height: 2-3/4″
Std Strike Number: 10-094
Std Strike Type: Square Corner
Std Strike Width: 1-1/8″
Subtype: Deadbolts
Type: Locks, Cylinders, Cores, Keyblanks
Unit of Measure: Each
Resources
- B500 Series Data Sheet
- B500 Series Deadbolts Cut Sheet
- B500 Series Installation Instructions
- B560, 61, 62, 63 Template
- B571 Template
- Schlage B Series Indicator Pricing Addendum
- Schlage B Series Service Manual
- Von Duprin Finishes Chart
