Description
Schlage L464J 626 Single Cylinder Mortise Deadbolt
Schlage L464J 626 Single Cyl Mortise Deadbolt offers a robust solution for securing storerooms and utility spaces, boasting a Grade 1 rating that ensures superior strength and durability. This cylinder-only model features a 6-pin FSIC configuration, providing flexibility for various keying options. The satin chrome finish not only enhances its aesthetic appeal but also adds a layer of corrosion resistance, making it suitable for commercial use. Designed specifically for applications where no latching is required, the L464J is ideal as a primary or auxiliary lock. It features a 1-inch stainless steel throw deadbolt, offering enhanced security against tampering. The deeper retainer groove in the cylinder shell further fortifies the lock against wrenching and pullout attempts.With dimensions of 4-7/16″ x 3-5/8″ x 1″, this lock fits standard doors of 1-3/4″ thickness. It includes a limited warranty of 3 years, ensuring peace of mind with your investment. The L400 Series also accommodates multiple functions and is backward compatible, making it a versatile choice for any security needs. For reliable performance and advanced security features, the Schlage L464J is a commendable option for both building professionals and discerning homeowners.
Single Cyl Mortise Deadbolt
Grade 1 Storeroom Small Case Mortise Deadbolt, Cylinder Only, 6-Pin FSIC Less Core, Satin Chrome Finish, Non-Handed
L400 Series locks are designed for use as primary locks where no latching is required, such as restrooms and small doors to utility spaces. It also offers optimum security when used as an auxiliary lock in other applications.
Designed for use as primary locks where no latching is required.
The L400 Seriesoffers optimum security when used as an auxiliary lock in other applications.
- Six available functions
- 12 finishes
- 1″ (25 mm) stainless steel throw deadbolt
- Deeper retainer groove in cylinder shell increases security against wrenching and pullout; all cylinders backward compatible
- 6-pin Everest® 29 cylinder with patented keys standard
- Steel case and parts are corrosion resistant
Attributes
Manufacturer surcharge: 4.5%
Ansi: ANSI/BHMA A156.36-2010, Grade 1
Ansi Function: E06081
Bolt Projection: 1″
Cam Number: L583-255
Cam Type: Schlage L
Case Dimensions: 4-7/16″ x 3-5/8″ x 1″
Commercial Residential: Commercial
Cylinder Length: 1-1/2″
Cylinder Type: Schlage 6-Pin FSIC Less Core
Door Thickness: 1-3/4″
Dust Box: Plastic
Faceplate Size: 5-9/16″ x 1-1/4″
Finish: 626/US26D
Finish Family: Matte Silver
Fire Rated: Yes
Fire Rating: 3 Hours {A}
Function: 464-Cylinder Only
Function Family: Storeroom
Grade: Grade 1
Handing: Non-Handed
Installation: Commercial
Latch Backset Dim: 2-3/4″
Limited Warranty: 3 Years
Lock Face Size: 5-9/16 ” x 1-1/4″
Pack Height: 3″
Pack Length: 6.5″
Pack Qty: 1
Pack Width: 5.75″
Pins: 6
Screws: Combination
Series: L400 Series Mortise Deadbolts
Ship Weight: 3 lbs.
Std Latch Backset Dim: 2-3/4″
Std Latch Number: L283-003
Std Latch Type: Deadbolt
Std Strike Height: 3-1/2″
Std Strike Number: 10-079
Std Strike Type: Flat
Std Strike Width: 1-1/8″
Subtype: Mortise Deadbolt Only
Type: Locks, Cylinders, Cores, Keyblanks
Ul Listing: UL/cUL Listed
Unit of Measure: Each
Resources
- L9000 Series Mortise Lock Cut Sheet
- Von Duprin Finishes Chart
