Description
Corbin Russwin ML2049 CSA 630 Storeroom Mortise Deadbolt Instructions
Corbin Russwin ML2049 CSA 630 Storeroom Deadbolt Mortise is a Grade 1 lock designed for high-traffic environments such as offices, schools, hospitals, and hotels. Built from heavy-gauge steel, this mortise lock features a robust lockbody and a patented quick reversible latchbolt, ensuring both security and convenience. The 1-inch stainless steel deadbolt adds an extra layer of strength, making it ideal for commercial, institutional, industrial, and government applications. With a sleek satin stainless steel finish, the ML2049 fits seamlessly into modern designs while offering durability and corrosion resistance. It is field-reversible, allowing easy adjustment without disassembling the lock, and it accommodates standard door thicknesses of 1-3/4 inches. The heavy-gauge lockcase measures 5-7/8″ x 4″ x 15/16″, and features a latchbolt with a 5/8″ x 1″ x 3/4″ throw for enhanced security. This lock meets Federal specifications FF-H-106C and is UL Listed, ensuring it meets the highest safety standards. With a 10-year warranty and a variety of trim designs available, the Corbin Russwin ML2049 is a versatile and reliable choice for any high-use application.
Stroreroom Deadbolt Mortise
Grade 1 Storeroom Mortise Lock, Citation Lever, A Rose, Conventional Cylinder, Satin Stainless Steel Finish, Field Reversible
The ML2000 Series Grade 1 Mortise Lock is designed to meet the rigors of high trasffic commercial, institutional, industrial and government applications. Constructed of heavy gauge steel, the lockbody features our patented quick reversible latchbolt and a 1″ stainless steel deadbolt. A wide variety of trim designsand functions with a 10 year warranty lend to the ML2000’s versatility and reliability, making it the ideal choice for use in offices, schools, hospitals, hotels and other high use applications.
The ML2000 series is a Grade 1 mortise lock designed to meet the rigors of high-traffic commercial, institutional, industrial and government applications.
The ML2000 Series is constructed of heavy-duty gauge steel and features a lockbody with the patented Quick Reversible latchbolt.A wide variety of trim designs and functions and a 10-year warranty lend to the ML2000’s versatility and reliability, making it the ideal choice for use in offices, schools, hospitals, hotels and other high-use applications.
- Handing: Handed; quick reversible. The lockset can be re-handed without disassembling the lock case.
- Door Thickness: 1-3/4″ (44mm) standard. Optional door thicknesses available.
- Backset: 2-3/4″ (70mm).
- Lockcase: Heavy-gauge steel, 5-7/8″ (149mm) x 4″ (102mm) x 15/16″ (24mm). Optional: non-ferrous lockcase for corrosion resistance.
- Front: Heavy-gauge steel, 8″ (203mm) x 1-1/4″ (32mm) x -3/32″ (2mm). Accommodates flat doors and doors beveled 1/8″ (3mm) in 2″ (51mm). Furnished 1-1/16″ (27mm), optional D138, wide for 1-3/8″ (35mm) doors.
- ArmoredFront: Wrought brass, bronze or stainless steel attached by machine screws to lockcase front. ML2000HS & ML2000VR utilizes security Torx® screws.
- Latchbolt: 2-piece mechanical with anti-friction insert, 5/8″ (16mm) x 1″ (25mm) x 3/4″ (19mm) throw.
- Keys: Two nickel silver standard.
- Federal: Meets FF-H-106C.
- Environmental Product Declaration: (EPD) certified
Attributes
Ansi: A156.13, Series 1000
Baa Qualified: Yes
Base Series: ML2000
Commercial Residential: Commercial
Country of origin: USA
Cylinder Type: Conventional Cylinder
Door Thickness: 1-3/4″
Finish: 630/US32D
Finish Family: Matte Silver
Fire Rated: 3 Hours {A}
Fire Rating: 3 Hours {A}
Function: 49-Storeroom
Grade: Grade 1
Handing: Field Reversible
Installation: Commercial
Keying: 0 Bitted
Keys: Blank
Leverknob Design: CS – Citation Lever
Limited Warranty: 10 Years
Lock Face Size: 8″ x 1-1/4″
Of Keys: 2
Origin: USA
Pack Height: 4.5″
Pack Length: 10″
Pack Qty: 1
Pack Width: 7.5″
Pins: 6
Roseescutcheon Design: A Rose
Series: ML2000 Series Mortise Locks
Ship Weight: 4 lbs.
Std Keyway: L4
Subtype: Mortise Lock
Type: Locks, Cylinders, Cores, Keyblanks
Ul Listing: UL Listed
Unit of Measure: Each
Unit of Measure 2: Case
Unit of Measure 2 Qty: 6
