LCN 1461-RW/PA 651 DS Surface Closer US26
LCN 1461-RW/PA 651 DS Surface Closer US26 delivers robust performance and adaptable installation options for various commercial and institutional settings. This Grade 1 tri-mount closer can be configured for push or pull-side installations and features a double lever arm with a designer metal cover in a sleek bright chrome finish. Engineered for versatility, it supports a full 180-degree swing and is left-handed, making it suitable for an array of door types. Constructed with a high-strength cast iron body, this closer is designed to withstand the test of time, having been rigorously tested for up to 2,000,000 cycles. The adjustable spring size, ranging from 1 to 6, allows for precise customization to meet specific door size and site conditions. Its independent adjustment valves enable fine-tuning of backcheck, closing, and latching speeds, all hidden behind the cover to deter tampering. The LCN 1461 includes a Cush-N-Stop® function to prevent damage during abrupt stops, ensuring longevity. Additionally, it meets ADA requirements and can be finished with custom powder coatings or plated options for enhanced aesthetics. With minimal maintenance needs, this closer is an excellent choice for building professionals seeking reliability and ease of installation.
Surface Closer US26
Grade 1 Tri Mount Surface Closer, Push or Pull Side, Double Lever Arm Regular, Designer Metal Cover, 180 Deg. Swing, With Parallel Arm Bracket, Bright Chrome Finish, Left-Handed
The LCN 1460 Series is designed for maximum versatility, available with multiple cover options, it can be used for both commercial and institutional applications. This Grade 1 closer features a cast iron body with a full compliment bearing, 1-1/4 In. diameter piston, 3/4 In. diameter single heat treated pinion journal and all weather fluid. Spring size is adjustable from size 1 to 6.
Universal medium-duty closer designed for maximum versatility that installs quickly and accurately.
The LCN 1460 Series isavailable with multiple cover options, can be used for both commercial and institutional applications. This fully universal closer offers a wide variety of options and new fast and accurate installation.
- Standard 1460 series closer shipped with regular arm, a slim line plastic cover, and self reaming and tapping screws
- Multiple cover options include; Standard (Slim line), Full and Designer Series
- Non-sized (1-6) cylinder is adjustable for interior doors to 5’0” and exterior doors to 4’0”
- Closer mounts hinge side, top jamb and parallel arm on either right or left swinging doors
- Closer meets ADA requirements
- Standard or optional custom powder coat finish. Optional plated finish on Designer Series metal cover, arm and fasteners
- Optional SRI primer for installations in corrosive conditions
1461 Series Features
- Universal, fully reversible, non-handed door closer
- Closer cylinder constructed of high strength cast iron for increased durability
- Tested to 2,000,000 cycles
- Fully adjustable 1-6 spring strength to suit door size and site conditions
- Factory set to strength 3
- Standard closer offers 3 installation options
- Regular (pull side)
- Top jamb (push side)
- Parallel arm (push side)
- Independent adjustment valves for adjusting backcheck, closing and latching speeds
- All adjustment valves are concealed behind the cover to prevent tampering
- Joints in arms and shoe brackets adapt to uneven mounting surfaces
- Stick-on template for fast, accurate installation. Cuts installation time in half
- Closers installed according to LCN installation instructions require minimal periodic maintenance or adjustments
- Cush-N-Stop® function has a built in stop incorporated into the arm to prevent damage to the closer, door or frame in the event of an abrupt stop
Attributes
Manufacturer surcharge: 4.5%
Baa Qualified: Yes
Base Material: Brass or Bronze
Cold Weather Fluid: Yes
Commercial Residential: Commercial
Cover: Designer Metal
Degree Hold Open: 180 Deg.
Degree Swing: 180 Deg.
Finish: 625/US26
Finish Family: Polished Silver
Grade: Grade 1
Handing: Non-Handed
Hold Open: No
Installation: Commercial
Limited Warranty: 30 Years
Mounting Group: Hydraulic
Mounting Location: Push or Pull Side
Mounting Style: Tri Mount
Pack Qty: 1
Pbs Options: 4404204
Series: 1460 Series Surface Mounted Closers
Ship Weight: 11 lbs.
Subtype: Surface Closers
Type: Surface
Unit of Measure: Each
