Description
Richelieu WEBKIT1249578 Terno Eclectica 160 Fluid
Richelieu WEBKIT1249578 TERNO ECLETTICA 160 FLUID is a highly efficient sliding door system designed specifically for wood doors weighing up to 160 kg (352 lb). This versatile solution is perfect for both residential and commercial applications, seamlessly facilitating access between rooms. One of the standout features of the TERNO ECLETTICA is its automatic clip-on suspension bracket, allowing for quick, tool-free installation. This system includes two soft-close mechanisms, ensuring a gentle and controlled closing action. The clip-on anodized aluminum fascia accommodates doors with thicknesses of 35 mm or 55 mm (1-3/8 in or 2-1/8 in), providing flexibility for various projects. For those looking to customize, optional clips for wood fascia can be supplied by the contractor. This top-hung sliding system supports door heights from 70-7/8 to 120 inches, with widths ranging from 35-3/8 to 70-7/8 inches. A groove is required at the bottom of the door for proper installation, and an optional two-part floor guide can be purchased separately to avoid the need for cutting. With a total length of 13 ft 1 in, the TERNO ECLETTICA 160 FLUID is a reliable choice for modern spaces, ensuring both functionality and aesthetic appeal.
TERNO ECLETTICA 160 FLUID
TERNO ECLETTICA 160 FLUID Series is a standard straight-sliding wood door system for wood doors weighing up to 160 kg (352 lb).
Features:
– Automatic clip-on suspension bracket for quick toolless door installation
– 2 soft close mechanisms
– Clip-on anodized aluminum fascia for 35 mm or 55 mm thick doors (1-3/8 in or 2-1/8 in)
– Optional clips for wood fascia supplied by the contractor
The TERNO ECLETTICA 160 FLUID Series is an ideal solution for high-volume residential and commercial projects as access doors between rooms.
IMPORTANT: Use metric dimensions for greater accuracy during installation.
Groove is required at the bottom of the door, see mounting instructions for details.
Optional two-part floor guide can be purchased separately to avoid the need to cut a groove in the door.
Attributes
Ship via: No UPS – Common Carrier Only
Application: Sliding Wall
Detailed Door Movement: Single sliding
Door Height: 70-7/8 to 120 in*
Door Installation: Top Hung
Door Material: Wood
Door Movement: Straight Sliding
Door Thickness: 1-3/8 to 2-5/32 in*
Door Width: 35-3/8 to 70-7/8 in*
Groove Needed for Guiding System: Yes
Minimum Door Width: 34 in*
Number of Doors: 1
Overall Length: 13 ft 1 in*
Product #: WEBKIT1249578
Roller Position: Upper
Roller Type: Ball Bearing
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84″ or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Soft- Close Type: FLUID, 2 Soft Close
Soft- Closing: Yes
Track Mounting: Ceiling Mount
