Richelieu WEBKIT1243407 Terno Eclectica 50 Fluid
Richelieu WEBKIT1243407 TERNO ECLETTICA 50 FLUID offers a sophisticated solution for straight sliding doors, accommodating wood doors weighing up to 50 kg. This versatile system is designed for seamless installation, featuring an automatic clip-on suspension bracket that allows for quick, toolless setup, making it perfect for both residential and commercial applications. The TERNO ECLETTICA 50 FLUID Series includes options for one soft-close mechanism with a shock absorber or two soft-close mechanisms, ensuring smooth and quiet operation. It is ADA compliant, with a low pull force of just 2.1 kg or less, making it accessible for everyone. The track can be mounted on the ceiling or wall, and it comes with clip-on anodized aluminum fascia options for doors ranging from 35 mm to 45 mm in thickness. For added functionality, the system requires a groove at the bottom of the door, but an optional two-part floor guide is available separately to eliminate the need for cutting. The TERNO ECLETTICA 50 FLUID is ideal for high-volume projects, offering a load capacity of 66.1 to 110 lbs and accommodating door widths of 29 1/8 to 39 3/8 inches. Enhance your space with this reliable and stylish sliding door solution.
TERNO ECLETTICA 50 FLUID
The TERNO ECLETTICA 50 FLUID Series is a standard straight sliding door system for wood doors weighing up to50 kg.
Features:
– Automatic clip-on suspension bracket for quick toolless door installation
– Choice ofhardware types
a) 1 soft close mechanism and 1 shock absorber
b) 2 soft close mechanisms
– ADA / Barrier-Free compliant with a low pull force of 2.1 kg or less
– Track options for ceiling mount and wall mount
– Clip-on anodized aluminum fascia options for 35 mm or 45 mm thick doors
– Optional clips for wood fascia supplied by the contractor
The TERNO ECLETTICA 50 FLUID Series is an ideal solution for high-volume residential and commercial projects for access doors between rooms.
IMPORTANT: Use metric dimensions for greater accuracy during installation.
Groove is required on the bottom of the door, see mounting instructions for details.
Optional two-part floor guide can be purchase separately to avoid cutting a groove.
Attributes
Ship via: No UPS – Common Carrier Only
Adjustable: Yes
Brand: Eclettica
Brand Model: Terno Eclettica
Detailed Door Movement: Single sliding
Door Height: 1 800 to 3 000 mm
Door Installation: Top Hung
Door Material: Wood
Door Movement: Straight Sliding
Door Thickness: 30 to 35 mm
Door Width: 740 to 1 000 mm
Function: Sliding Door
Groove Depth: 14 mm
Groove Needed for Guiding System: Yes
Groove Width at the Bottom of Door: 6 mm
Length – Overall Dimensions: 13 ft 1 in*
Load Capacity: 66.1 to 110 lb*
Manufacturing Material: Aluminum
Number of Doors: 2
Overall Length: 4 000 mm
Product #: WEBKIT1243407
Product №: WEBKIT1243407
Roller Type: Ball Bearing
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84″ or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Soft- Close Type: Two Soft-close
Soft- Closing: Yes
Track Material: Anodized Aluminum
Track Mounting: Wall Mount
Weight Capacity per Door: 30 to 50 kg
