Description
Model 801 Deluxe Ironworker® kit contains quality equipment needed for cutting, brazing, and welding using oxygen and acetylene gases. The kit can cut up 4 in. (101.6mm) and is supplied with a tip to cut up to 1 in. (25.4mm) plate. The kit can braze up to 3 in. (76.2) diameter copper tube and is supplied with a size tip for brazing copper up to 1 1/2 in. (38.1mm) tube. The kit is capable of welding up to 1/2 in. (12.7mm) and is supplied with a tip that welds up to 1/16 in. (1.6mm) plate.
This kit has the V-Series 2-tube cutting attachment design and thread. The fuel regulator cylinder connection is CGA 510. This kit can cut up to 4 in., braze up to 3 in. copper tube and weld up to 1/2 in. plate.
Model 801 Deluxe Ironworker® kit contains quality equipment needed for cutting, brazing, and welding using oxygen and acetylene gases. The kit can cut up 4 in. (101.6mm) and is supplied with a tip to cut up to 1 in. (25.4mm) plate. The kit can braze up to 3 in. (76.2) diameter copper tube and is supplied with a size tip for brazing copper up to 1 1/2 in. (38.1mm) tube. The kit is capable of welding up to 1/2 in. (12.7mm) and is supplied with a tip that welds up to 1/16 in. (1.6mm) plate.
Medium Duty 2-tube design kit to be used with oxygen and acetylene gases.
Regulator oxygen and acetylene Model 801 with easy-to-read dual scale 2 in. gauges, ergonomic plastic adjusting knob, neoprene diaphragms and our distinguished internal encapsulated seat filter. Oxygen regulator delivers up to 145 psi and acetylene regulator delivers up to 15 psi.
Torch handle Model VH10 that has tube-within-a-tube construction and is equipped with external replaceable FlashGuard® check valves.
Cutting attachment model VH13 features a stainless-steel lever, an in-tube mixer, and threaded connections for easy repair.
Consumables included: V3-101-1 cutting tip, V-W-1 mixer and 23A90-5 welding tip.
Accessories included: Shade 5 safety glasses (ANSI Z87.1 CE Weld), Handheld ignitor, 1/4 in. x 20 ft. twin R-grade hose and Harris black and red insulated tool kit bag.
Model 801-15-510 Fuel Gas Regulator – 3002193,Model 801-145-540 Oxygen Regulator – 3002194,Model VH10 Torch Handle – 1400424,Model VH13 Cutting Attachment – 1300048,Model V-W1 MD Mixer Assembly – 9105213,Model V3-101-1 Cutting Tip – 1502083,Model 23A90-5 Welding Tip – 1600890,1/4 in. x 20 ft. Twin B&B R-Grade Oxy-Acetylene Hose – 4300591,Safety Glasses Shade 5 – 4303629,Handheld Ignitor – 9004486,Harris Insulated Tool Kit Bag – 8855094,Trilingual Kit Manual – 9505643,V-Series Tip Chart – 9500688
Regulators: 7 Years;All other components: 1 Year
VMD VH10801-510 DLX
Harris
Acetylene
Cutting Attachment Model Number: VH-13
Cutting Capacity: Up to 4 in. (101.6mm) plate with optional tip(s);Optional tip(s) sold separately
Cutting Tip Style – Acetylene-H2 (Size): V3-101-1
Duty: Medium
Equipped With: FlashGuard® check valves – handle
Fuel Gas Regulator Model Number: 801-15-510
Gas / Gas Service: Acetylene
Gauges: 2 in. Steel dual scale (psi/kPa) – regulators
Hose Connection/Fittings: BxB
Hose Size: 1/4 in. x 20 ft.
Hose Type: Twin Oxygen-Acetylene R-grade
Included Accessories: Shade 5 safety glasses (ANSI Z87.1 CE Weld);Handheld ignitor;1/4 in. x 20 ft. twin BxB R-grade hose;Harris black and red insulated tool kit bag
Mixer Model Number: V-W-1
Mixer Type: E-Equal or positive pressure
Oxygen Regulator Model Number: 801-145-540
Recommended Items/Accessories: Standard One-Piece Tip Cleaner – Model C-9 – PN 9000156;Deluxe Two-Piece Tip Cleaner – Model E-9 – PN 9000160
Seat: PTFE Teflon® – regulators
Tank Connection: CGA 540, CGA 510
Torch Handle Model Number: VH31
Welding Capacity: Up to 1/2 in. (12.7mm) plate with optional tip(s). Optional tips sold separately
Welding/Brazing Tip Model Number – Acetylene: 23A90-5
What’s Included: Model 801-15-510 Fuel Gas Regulator – 3002193,Model 801-145-540 Oxygen Regulator – 3002194,Model VH10 Torch Handle – 1400424,Model VH13 Cutting Attachment – 1300048,Model V-W1 MD Mixer Assembly – 9105213,Model V3-101-1 Cutting Tip – 1502083,Model 23A90-5 Welding Tip – 1600890,1/4 in. x 20 ft. Twin B&B R-Grade Oxy-Acetylene Hose – 4300591,Safety Glasses Shade 5 – 4303629,Handheld Ignitor – 9004486,Harris Insulated Tool Kit Bag – 8855094,Trilingual Kit Manual – 9505643,V-Series Tip Chart – 9500688
Model Name: VMD VH10801-510 DLX
