Description
MS Sedco TC30 Vehicle Presence Sensor Guide
MS Sedco TC30 Vehicle Presence Sensor offers advanced ultrasonic technology for reliable vehicle detection in various applications. Designed for single lane or area monitoring, this sensor provides true presence detection, making it an ideal, cost-effective replacement for traditional loop detectors. With an adjustable detection range of up to 22 feet, the TC30 is versatile enough for use with automatic gates, toll booths, highway traffic management, loading docks, and other parking control scenarios. Mounting above ground, the TC30 eliminates the need for pavement cuts, ensuring easy installation with minimal disruption to traffic flow. This feature is particularly beneficial for busy environments where downtime must be minimized. The sensor operates at 24 VDC and has a relay type of Form C, supporting efficient integration into existing systems. Included in the extensive range of MS Sedco accessories are mounting boxes, jamb boxes, post assemblies, wall mount transmitters, and face plates, providing comprehensive solutions for door activation and monitoring needs. Whether for commercial installations or specialized applications, the TC30’s robust design and user-friendly features ensure optimal performance and reliability. Enhance your vehicle detection capabilities with the MS Sedco TC30, a smart choice for modern traffic management.
Vehical Presence Sensor
Ultrasonic Vehicle Presence Sensor, True Presence Detection of Single Lane/Area, Inexpensive Loop Detector Replacement, Installs Easily Above Ground, Adjustable Range up to 22 Feet
The TC30 is an ultrasonic sensor designed for detecting vehicle presence. It can also be used with automatic gates, toll booths, for highway traffic management, loading dock monitoring and other parking control applications. The TC30 mounts above ground, requires no pavement cuts and can be installed with minimal or no traffic disruption
MS Sedco accessories including switches, mounting boxes and face plates.
MS Sedco accessories range across their family of door activation products. These accessories apply to MS Sedco items such as ClearPath Packges, door activation switches, infrared switches and keyswitches.
Accessories include (but are not limited to):
- Mounting Boxes
- Jamb Boxes
- Post Assemblies
- Wall Mount Transmitters
- Face Plates
…and more!
Attributes
Commercial Residential: Commercial
Installation: Commercial
Line Draw: 75 mA
Operating Voltage: 24 VDC
Pack Qty: 1
Range: 22 Feet
Relay Type: Form C
Relays: 1
Sensor Technology: Ultrasonic
Series: MS Sedco Electrical Accessories
Subtype: Motion Sensors
Timer Duration: 0.25 – 10 Seconds
Type: Sensors, Switches, Relays, Timers
Unit of Measure: Each
Resources
- MS Sedco 514 Series Data Sheet
- MS Sedco 514 Series Installation Instructions
- MS Sedco 608 Series Cut Sheet
- MS Sedco 608 Series Data Sheet
- MS Sedco 608 Series Installation Instructions
- MS Sedco Switch Mounting Box Compatibility Chart
