Yale AUCN8861FL 626 LC Dormitory Mortise Lock with Deadbolt Instructions
Yale AUCN8861FL 626 LC Dormitory Mortise Lock Dbolt offers robust security and reliability, making it ideal for dormitory or storeroom applications. This Grade 1 mortise lock features an elegant Augusta lever and a CN escutcheon, all finished in a sleek satin chrome that complements any commercial environment. Designed for exceptional strength, the Yale 8800 Series Mortise Locks are constructed with a reinforced stainless steel deadbolt and heavy-duty, vandal-resistant trim. The lock’s ANSI/BHMA Grade 1 certification ensures long-lasting durability and performance, suitable for high-traffic areas. Installation is straightforward, thanks to features like quick lever handing, a field-reversible latchbolt, and a standard nonhanded strike. The lock accommodates standard door thicknesses of 1-3/4″, with options for thicker doors up to 3-1/4″. It includes a 3/4″ stainless steel throw latchbolt and comes with a brass, 6-pin keyed-random cylinder, two keys included. The AUCN8861FL is also UL/cUL fire rated for up to 3 hours, adding an extra layer of safety. With 17 available finishes and a 10-year mechanical warranty, this mortise lock is an excellent choice for those seeking both style and security.
Dormitory Mortise Lock Dbolt
Grade 1 Dormitory or Storeroom Mortise Lock, Augusta Lever, CN Escutcheon, Less Cylinder, Satin Chrome Finish
Yale 8800 Series Mortise Locks are designed and manufactured for uncompromising strength and durability in a range of commercial applications. Lock installation is made easy with quick lever handing, field reversible latchbolt and standard nonhanded strike. The 8800 Series Mortise Lock offers a new measure of security, featuring a reinforced stainless steel deadbolt, heavy-duty, vandal-resistant trim and ANSI/BHMA Grade 1 certification for long life and durability.
Lock installation is easy with quick lever handing, field reversible latchbolt and standard nonhanded strike.
The 8800 Series Mortise Lock offers a new measure of security, featuring a reinforced stainless steel deadbolt, heavy-duty, vandal-resistant trim and ANSI/BHMA Grade 1 certification for long life and durability.
- ANSI/BHMA:Certified ANSI/BHMA A156.13, Series 1000, Operational Grade 1
- UL-cUL:UL/cUL fire rated up to 3 hours
- Windstorm:Certified (refer to local codes)
- Mechanism:Stainless steel
- Backset:2-3/4″
- Latchbolt:3/4″ stainless steel throw
- Door Thickness:1-3/4″ standard, to 3-1/4″ thick doors to order
- Fronts:Bevel front, free-floating to adjust from flat to standard bevel of 1/8″ in 2″
- Cylinders:Brass, 6-pin, keyed-random cylinder with two keys furnished standard, 7-pin available to order
- Reversibility:Field reversible handing
- Strikes:1-1/4″ curved lip for 1-3/4″ door standard; other lip lengths to special order; all reversible
- Finishes:Available in 17 finishes
- Warranty:10 year mechanical
Attributes
Commercial Residential: Commercial
Cylinder Type: Less Cylinder
Finish: 626/US26D
Finish Family: Matte Silver
Function: 61-Dormitory or Storeroom Lock
Grade: Grade 1
Installation: Commercial
Leverknob Design: AU – Augusta Lever
Pack Qty: 1
Roseescutcheon Design: CN Escutcheon
Series: Yale 8800 Series Mortise Locks
Subtype: Mortise Lock
Type: Locks, Cylinders, Cores, Keyblanks
Unit of Measure: Each
Resources
- 2023 Yale Commercial Price Book (effective 4.17.2023)
- 8800 Series Handing Instructions
- 8800 Series Mortise Lock – Environmental Product Declaration (EPD)
- 8800 Series Mortise Lock Installation Instructions
- 8800 Series Parts Manual
- 8800 Series Upgrade Solutions Sell Sheet
- 8800-ITS Mortise Lockset Installation Instructions
- Yale 8800 Series Mortise Lock Catalog
- Yale 8800 Series Mortise Lock with Status Indicators Sell Sheet
- Yale 8800 Series Mortise Locks Cut Sheet
- Yale Commercial Finishes Chart
- Yale Competitor Indicator Kits Catalog
- Yale Reflections Catalog
