Description
Yale LBDY8801FL 626 Passage Mortise Lock Body
Yale LBDY8801FL 626 Passage Mortise Lock Body is a robust Grade 1 lever mortise lock designed for commercial applications, ensuring uncompromising strength and durability. Finished in a sleek satin chrome, this lock combines aesthetic appeal with functionality. The passage function allows for smooth operation in areas where locking is not required, making it ideal for hallways and closets. Engineered with convenience in mind, the Yale 8800 Series Mortise Lock features quick lever handing and a field-reversible latchbolt, facilitating hassle-free installation. The reinforced stainless steel deadbolt enhances security, while the heavy-duty, vandal-resistant trim promises longevity in high-traffic environments. This lock is certified to ANSI/BHMA Grade 1 standards, ensuring reliability and performance. Additional specifications include a 2-3/4″ backset, a 3/4″ stainless steel throw latchbolt, and compatibility with doors ranging from 1-3/4″ to 3-1/4″ thick. The bevel front is adjustable for easy installation, and the brass, 6-pin keyed cylinder comes with two keys for added convenience. With a warranty of 10 years on mechanical components, the Yale LBDY8801FL is a trusted choice for professionals seeking quality and reliability in door hardware.
Passage Mortise Lock Body
Grade 1 Lever Mortise Lock Body, Passage Function, Satin Chrome Finish
Yale 8800 Series Mortise Locks are designed and manufactured for uncompromising strength and durability in a range of commercial applications. Lock installation is made easy with quick lever handing, field reversible latchbolt and standard nonhanded strike. The 8800 Series Mortise Lock offers a new measure of security, featuring a reinforced stainless steel deadbolt, heavy-duty, vandal-resistant trim and ANSI/BHMA Grade 1 certification for long life and durability.
Lock installation is easy with quick lever handing, field reversible latchbolt and standard nonhanded strike.
The 8800 Series Mortise Lock offers a new measure of security, featuring a reinforced stainless steel deadbolt, heavy-duty, vandal-resistant trim and ANSI/BHMA Grade 1 certification for long life and durability.
- ANSI/BHMA:Certified ANSI/BHMA A156.13, Series 1000, Operational Grade 1
- UL-cUL:UL/cUL fire rated up to 3 hours
- Windstorm:Certified (refer to local codes)
- Mechanism:Stainless steel
- Backset:2-3/4″
- Latchbolt:3/4″ stainless steel throw
- Door Thickness:1-3/4″ standard, to 3-1/4″ thick doors to order
- Fronts:Bevel front, free-floating to adjust from flat to standard bevel of 1/8″ in 2″
- Cylinders:Brass, 6-pin, keyed-random cylinder with two keys furnished standard, 7-pin available to order
- Reversibility:Field reversible handing
- Strikes:1-1/4″ curved lip for 1-3/4″ door standard; other lip lengths to special order; all reversible
- Finishes:Available in 17 finishes
- Warranty:10 year mechanical
Attributes
Ansi Function: F01 – Passage
Commercial Residential: Commercial
Finish: 626/US26D
Finish Family: Matte Silver
Function: 01-Passage or Closet Latch
Grade: Grade 1
Installation: Commercial
Pack Qty: 1
Series: Yale 8800 Series Mortise Locks
Subtype: Lock Bodies
Type: Locks, Cylinders, Cores, Keyblanks
Unit of Measure: Each
Resources
- 2023 Yale Commercial Price Book (effective 4.17.2023)
- 8800 Series Handing Instructions
- 8800 Series Mortise Lock – Environmental Product Declaration (EPD)
- 8800 Series Mortise Lock Installation Instructions
- 8800 Series Parts Manual
- 8800 Series Upgrade Solutions Sell Sheet
- 8800-ITS Mortise Lockset Installation Instructions
- Yale 8800 Series Mortise Lock Catalog
- Yale 8800 Series Mortise Lock with Status Indicators Sell Sheet
- Yale 8800 Series Mortise Locks Cut Sheet
- Yale Commercial Finishes Chart
- Yale Competitor Indicator Kits Catalog
- Yale Reflections Catalog
