Yale MOR8802FL BSP Privacy Mortise Lock with D-Bolt
Yale MOR8802FL BSP Privacy Mortise Lock w/D-Bolt offers a robust solution for enhancing security in commercial spaces. This Grade 1 privacy lock features a deadbolt mechanism designed for reliable performance, making it ideal for applications such as bedrooms and bathrooms. The Monroe lever and CO rose design add a touch of elegance, while the black suede powder coat finish ensures durability against wear and tear. Engineered for strength, the lock boasts a reinforced stainless steel deadbolt and heavy-duty, vandal-resistant trim, meeting ANSI/BHMA Grade 1 certification for long-lasting reliability. Installation is straightforward, thanks to quick lever handing, a field-reversible latchbolt, and a standard nonhanded strike. With a backset of 2-3/4″ and compatibility with doors ranging from 1-3/4″ to 3-1/4″ in thickness, this mortise lock adapts to various door specifications. Additionally, it is UL/cUL fire-rated for up to three hours, enhancing safety in emergencies. The lock comes with a brass, 6-pin keyed-random cylinder, along with two keys. Available in 17 different finishes, the Yale MOR8802FL ensures that security does not compromise style. With a 10-year mechanical warranty, this lock is built to last, making it a smart choice for any professional setting.
Privacy Mortise Lock w/D-Bolt
Grade 1 Privacy with Deadbolt Mortise Lock, Monroe Lever, CO Rose, Black Suede Powder Coat Finish
Yale 8800 Series Mortise Locks are designed and manufactured for uncompromising strength and durability in a range of commercial applications. Lock installation is made easy with quick lever handing, field reversible latchbolt and standard nonhanded strike. The 8800 Series Mortise Lock offers a new measure of security, featuring a reinforced stainless steel deadbolt, heavy-duty, vandal-resistant trim and ANSI/BHMA Grade 1 certification for long life and durability.
Lock installation is easy with quick lever handing, field reversible latchbolt and standard nonhanded strike.
The 8800 Series Mortise Lock offers a new measure of security, featuring a reinforced stainless steel deadbolt, heavy-duty, vandal-resistant trim and ANSI/BHMA Grade 1 certification for long life and durability.
- ANSI/BHMA:Certified ANSI/BHMA A156.13, Series 1000, Operational Grade 1
- UL-cUL:UL/cUL fire rated up to 3 hours
- Windstorm:Certified (refer to local codes)
- Mechanism:Stainless steel
- Backset:2-3/4″
- Latchbolt:3/4″ stainless steel throw
- Door Thickness:1-3/4″ standard, to 3-1/4″ thick doors to order
- Fronts:Bevel front, free-floating to adjust from flat to standard bevel of 1/8″ in 2″
- Cylinders:Brass, 6-pin, keyed-random cylinder with two keys furnished standard, 7-pin available to order
- Reversibility:Field reversible handing
- Strikes:1-1/4″ curved lip for 1-3/4″ door standard; other lip lengths to special order; all reversible
- Finishes:Available in 17 finishes
- Warranty:10 year mechanical
Attributes
Ansi Function: F19 – Privacy/Bed/Bath
Bolt Projection: 3/4″
Commercial Residential: Commercial
Door Thickness: 1-3/4″
Finish: BSP
Finish Family: Black
Fire Rated: 3 Hours {A}
Fire Rating: 3 Hours {A}
Function: 02-Privacy, Bedroom or Bath Lock
Grade: Grade 1
Installation: Commercial
Leverknob Design: MO – Monroe Lever
Limited Warranty: 10 Years
Lock Face Size: 8″ x 1-1/4″
Pack Qty: 1
Roseescutcheon Design: CO Rose
Series: Yale 8800 Series Mortise Locks
Std Latch Backset Dim: 2-3/4″
Std Strike Height: 4-7/8″
Std Strike Number: 2815
Std Strike Type: ASA
Subtype: Mortise Lock
Type: Locks, Cylinders, Cores, Keyblanks
Unit of Measure: Each
Resources
- 2023 Yale Commercial Price Book (effective 4.17.2023)
- 8800 Series Handing Instructions
- 8800 Series Mortise Lock – Environmental Product Declaration (EPD)
- 8800 Series Mortise Lock Installation Instructions
- 8800 Series Parts Manual
- 8800 Series Upgrade Solutions Sell Sheet
- 8800-ITS Mortise Lockset Installation Instructions
- Yale 8800 Series Mortise Lock Catalog
- Yale 8800 Series Mortise Lock with Status Indicators Sell Sheet
- Yale 8800 Series Mortise Locks Cut Sheet
- Yale Commercial Finishes Chart
- Yale Competitor Indicator Kits Catalog
- Yale Reflections Catalog
