Yale LBDY8823FL 626 Store Room Mortise Lock Body
Yale LBDY8823FL 626 Storeroom Mortise Lock Body offers exceptional strength and security ideal for a variety of commercial applications. This Grade 1 Lever Mortise Lock Body features a storeroom function with a robust deadbolt, ensuring reliable access control. Its satin chrome finish not only enhances aesthetics but also provides durability against wear. Designed for ease of installation, the Yale 8800 Series Mortise Lock includes quick lever handing, a field-reversible latchbolt, and a standard nonhanded strike. Built with a reinforced stainless steel deadbolt and heavy-duty, vandal-resistant trim, it meets ANSI/BHMA Grade 1 certification standards for long-lasting performance. Additionally, it is UL/cUL fire rated for up to three hours, ensuring safety in emergencies. With a backset of 2-3/4 inches and compatibility for door thicknesses from 1-3/4 inches to 3-1/4 inches, the lock adapts to various door specifications. The included 6-pin brass cylinder provides added security, with the option for a 7-pin available upon request. Available in 17 finishes, the Yale LBDY8823FL combines functionality with style, making it an excellent choice for any commercial space. Backed by a 10-year mechanical warranty, this lock body is built for reliability and peace of mind.
Storeoom Mortise Lock Body
Grade 1 Lever Mortise Lock Body, Storeroom with Deadbolt Function, Satin Chrome Finish
Yale 8800 Series Mortise Locks are designed and manufactured for uncompromising strength and durability in a range of commercial applications. Lock installation is made easy with quick lever handing, field reversible latchbolt and standard nonhanded strike. The 8800 Series Mortise Lock offers a new measure of security, featuring a reinforced stainless steel deadbolt, heavy-duty, vandal-resistant trim and ANSI/BHMA Grade 1 certification for long life and durability.
Lock installation is easy with quick lever handing, field reversible latchbolt and standard nonhanded strike.
The 8800 Series Mortise Lock offers a new measure of security, featuring a reinforced stainless steel deadbolt, heavy-duty, vandal-resistant trim and ANSI/BHMA Grade 1 certification for long life and durability.
- ANSI/BHMA:Certified ANSI/BHMA A156.13, Series 1000, Operational Grade 1
- UL-cUL:UL/cUL fire rated up to 3 hours
- Windstorm:Certified (refer to local codes)
- Mechanism:Stainless steel
- Backset:2-3/4″
- Latchbolt:3/4″ stainless steel throw
- Door Thickness:1-3/4″ standard, to 3-1/4″ thick doors to order
- Fronts:Bevel front, free-floating to adjust from flat to standard bevel of 1/8″ in 2″
- Cylinders:Brass, 6-pin, keyed-random cylinder with two keys furnished standard, 7-pin available to order
- Reversibility:Field reversible handing
- Strikes:1-1/4″ curved lip for 1-3/4″ door standard; other lip lengths to special order; all reversible
- Finishes:Available in 17 finishes
- Warranty:10 year mechanical
Attributes
Commercial Residential: Commercial
Finish: 626/US26D
Finish Family: Matte Silver
Function: 23-Storeroom Lock
Grade: Grade 1
Installation: Commercial
Pack Qty: 1
Series: Yale 8800 Series Mortise Locks
Subtype: Lock Bodies
Type: Locks, Cylinders, Cores, Keyblanks
Unit of Measure: Each
